Can I move a dell inspiron 620 motherboard to a corsair 200r?

Tags:
  • Motherboards
  • Dell Inspiron
  • Corsair
Last response: in Motherboards
Share
February 11, 2014 5:54:44 PM

I had to fit in a Sapphire Radeon hd 7950 It didnt fit, obviously and I kept procastinating in upgrading my case and now all I want to buy is the case and nothing else, (I will buy led fans)
I just need help with like the front ports..
Will the motherboard be able to work with the corsair 200r front.
So yep...
I have pins on my motherboard but no labels?
http://www.dhresource.com/albu_448159859_00-1.0x0/for-d...

I have like a entire plug and it is the front panel stuff

Please please Help me out! :(

More about : move dell inspiron 620 motherboard corsair 200r

a b V Motherboard
February 11, 2014 6:25:11 PM

The mounting holes look like they're in common positions for a microatx board, so it should be possible to mount it in a Corsair 200R. Also, the 24-pin power connector looks like is has keyed pins that match an atx power connector, so it might not be using an incompatible proprietary variation. However, the lack of labels for the front panel connectors that you noticed is likely to be more of a problem, and I wouldn't expect Dell to have provided a motherboard manual. I don't know whether it's safe to experiment to determine which of the front panel connection pins is for what.
m
0
l
February 11, 2014 8:35:59 PM

MauveCloud said:
The mounting holes look like they're in common positions for a microatx board, so it should be possible to mount it in a Corsair 200R. Also, the 24-pin power connector looks like is has keyed pins that match an atx power connector, so it might not be using an incompatible proprietary variation. However, the lack of labels for the front panel connectors that you noticed is likely to be more of a problem, and I wouldn't expect Dell to have provided a motherboard manual. I don't know whether it's safe to experiment to determine which of the front panel connection pins is for what.


How can I do this?
So most of the part is a yes its just the labeling part thats a problem?
There is a manual online though
ftp://ftp.dell.com/Manuals/all-products/esuprt_desktop/...
m
0
l
Related resources
February 11, 2014 8:38:50 PM

MauveCloud said:
The mounting holes look like they're in common positions for a microatx board, so it should be possible to mount it in a Corsair 200R. Also, the 24-pin power connector looks like is has keyed pins that match an atx power connector, so it might not be using an incompatible proprietary variation. However, the lack of labels for the front panel connectors that you noticed is likely to be more of a problem, and I wouldn't expect Dell to have provided a motherboard manual. I don't know whether it's safe to experiment to determine which of the front panel connection pins is for what.


Actually will anything on page 43 help?
m
0
l
a b V Motherboard
February 11, 2014 9:36:55 PM

Page 43 helps, yes. But not in the way you might hope. :(  Since it lables that 15-pin interface (#7) as a single interface for the power button, I'm pretty sure it won't work with the standard ATX front panel connectors for the power button, reset button, power led, and hdd led, which each only require 2 pins (although I think one of them can have an empty pin between the two, I forget which), for a total of 8. 5 pins for the internal speaker is a bit strange as well. The headers for front USB and front-panel audio look standard, but that doesn't help much if you can't connect the power button.
m
0
l
February 12, 2014 9:52:43 AM

MauveCloud said:
Page 43 helps, yes. But not in the way you might hope. :(  Since it lables that 15-pin interface (#7) as a single interface for the power button, I'm pretty sure it won't work with the standard ATX front panel connectors for the power button, reset button, power led, and hdd led, which each only require 2 pins (although I think one of them can have an empty pin between the two, I forget which), for a total of 8. 5 pins for the internal speaker is a bit strange as well. The headers for front USB and front-panel audio look standard, but that doesn't help much if you can't connect the power button.


Um could you say that simpler?
What do i do?
m
0
l
a b V Motherboard
February 12, 2014 10:08:25 AM

I think you'll have to get a new motherboard to be able to use a new case.
m
0
l
February 12, 2014 3:39:23 PM

MauveCloud said:
I think you'll have to get a new motherboard to be able to use a new case.


Okay so just a new motherboard? thats it right?
