[Solved] Graphics card/PSU question

Forum Graphic & Displays : Graphics Cards - [Solved] Graphics card/PSU question

Tom's Hardware: Over 1.4 million members in 6 different countries available to answer all your high-tech questions. Sign up now! Its free!
Ask the community Add a reply

Best answer from 4745454b.

Word :    Username :

pph   09-20-2009 at 10:13:54 PM

I have a Gateway DX4300-05. It has the HD 3200 integrated graphics. I want to upgrade the card for medium range gaming. Currently, the only PC game I own is Call of Duty: WaW. While CoD: WAW is playable a low settings, it's still pretty choppy. I'm not a heavy gammer (yet), but I'll be purchasing CoD 6: MW2 when it's available. And I'm sure I will be getting some other games. I just want a video card that can make things a little smoother.

Right now I can't afford to upgrade my PSU and graphics card. I WILL update my PSU later and get a better graphics card. But, for now, I would like to know what is the best video card I can upgrade too without upgrading my current PSU. I've got a 300W stock PSU. But I know that there are a lot of variables when it comes to PSUs. So check out the pics below. They should contain all the info you need.



http://i661.photobucket.com/albums/uu336/pph7/DSC00002.jpg
http://i661.photobucket.com/albums/uu336/pph7/DSC00011.jpg

I know I can crossfire with an HD 3470, but I think I'd be better off getting a better card and disabling the 3200 all together.

Price range: nothing higher than $60.00

Rest of the specs below.

****************************************************************
Processor

* Type AMD Athlon X2 7750 / 2.7 GHz
* Multi-Core processor technology Dual-Core
* 64-bit processor Yes
* Installed Qty 1
* Max processors supported 1

Cache Memory

* Type L2 cache
* Installed Size 1 MB

RAM

* Installed Size 6 GB
* Technology DDR2 SDRAM
* RAM form factor DIMM 240-pin



Graphics Controller

* Graphics Processor / Vendor ATI Radeon HD 3200 Shared video memory (UMA)
* Video Memory 512 MB
* Max Allocated RAM Size 512 MB


Expansion / Connectivity

1 ( 0 ) x Processor,
Memory - DIMM 240-pin,
1 ( 1 ) x PCI Express x1,
1 ( 1 ) x PCI Express x16,
2 ( 2 ) x PCI


Message edited by pph on 09-20-2009 at 10:14:24 PM
Add a reply
Best answer from 4745454b
Theres no 12v1 + 12v2 listed on that PSU, so we have to guess. There are a couple of ways we can. If the total output is 300W, and the 3.3v + 5v can use up to 130W, this leaves (300 - 130) 170W for the 12V rails. (170 / 12) - 2A for the other rails leaves you around 12A worst case. I doubt you'd ever use that much for the 3.3 and 5v rails however as this is a modern system. Looking at the rail distribution, I'd guess that the 12v1 (8A) is for the motherboard and CPU. The 12v2 (14A) is for everything else. 14A isn't a lot, more so if it has to be shared by powering drives and other things. I would stick to those cards that don't need any extra power, the best of which is the 4670. (there are some low power 9600GTs out there, but they are expensive.) I'd look for one of them first.
Sponsored Links
Register or log in to remove.
Bronze Graphics badge hunter315   09-20-2009 at 10:22:55 PM

Depending on how strict that $60 limit is here is one for $61
http://www.newegg.com/Product/Prod [...] 6814161285

Here is a better card for $60 after $10 MIR
http://www.newegg.com/Product/Prod [...] 6814121329

Reply to hunter315
FallenSniper   09-20-2009 at 10:27:05 PM

That's a pretty light power supply when it comes to video cards. Here's a possibility: http://www.newegg.com/Product/Prod [...] 814121320.

Reply to FallenSniper
4745454b   09-20-2009 at 10:38:17 PM
Best answer

Theres no 12v1 + 12v2 listed on that PSU, so we have to guess. There are a couple of ways we can. If the total output is 300W, and the 3.3v + 5v can use up to 130W, this leaves (300 - 130) 170W for the 12V rails. (170 / 12) - 2A for the other rails leaves you around 12A worst case. I doubt you'd ever use that much for the 3.3 and 5v rails however as this is a modern system. Looking at the rail distribution, I'd guess that the 12v1 (8A) is for the motherboard and CPU. The 12v2 (14A) is for everything else. 14A isn't a lot, more so if it has to be shared by powering drives and other things. I would stick to those cards that don't need any extra power, the best of which is the 4670. (there are some low power 9600GTs out there, but they are expensive.) I'd look for one of them first.

------------------------------ The voice of REASON
Do NOT feed the TROLLS!
Always a DEMON!
 Reply to 4745454b
FallenSniper   09-20-2009 at 10:40:55 PM

If the 4670 doesn't use much power then it gets my vote. I was gonna post it but for some reason I thought it used more power... -_-;

Reply to FallenSniper
pph   09-20-2009 at 11:08:04 PM

Thanks for all the replys. I've been looking at the 4650/4670s and will probably end up going with one or the other. I was just worried that my PSU might not be able to handle that card.

I'll probable go with the 4650 for now. Probably the safest bet. And again.. its only temporary. Thanks for the info fellers!


Message edited by pph on 09-20-2009 at 11:08:36 PM
