Finished My Build (56k warning)

Last response: in Systems
Share
February 4, 2010 5:16:17 PM

I want to thank everyone here for their assistance in my latest foray. It was a smooth process, the only hangup was my HSF fan shipped DOA. I'm currently using the cases exaust fan while Newegg handles my RMA. Recap of system then a few benches and a single grainy pic of my monitors. I'll follow up with a few pics of the case/components once I get the new fan and can finish sleeving.

i7-860
Asus Sabertooth
Corsair XMS 4x2gb 9-9-9-24 1333
MSI ATI Radeon 5870
OCZ Solid Series 2 60gb x 2 RAID0
Seagate 7200.12 500gb x 2 RAID0
Lancool K-62
ABS 850w 80+ Silver Modular
Prolimatech Megahalems /w Panaflo 120x38
Scythe Fan Controller
Sony Optiarc DVDR/W
Dell 2209wa x 3 3150 x 1680 Eyefinity Portrait
Steelseries Merc
Microsoft Sidewinder
Sony DAV-HDX576WF 5.1 Surround

860 is at 3.6 which I feel is a great spot for these Quads with HT. I had it at 4.2~ for a few minutes, everything loaded but I did not prime95 that speed. At the end of the day 3.6 with turbo and HT is a good spot for me. Overnight prime95 was still running the next morning. Blck 200, multiplier 18, stock volts.

The RAM is oc'd to 2000 @ 8-8-8-22 memtested through 8 passes. I was exceptionally suprised with this. First it's 2 separate kits of 4gb, second it was only rated for 1333. Not a single voltage increase, motherboard set it at these speeds after I set blck to 200. Multiplier of 10.

cpu-z, superpi 1.5 1m, windows experience (7.9 is max score possible)


2x 500gb Seagate 7200.12 in RAID0


2x 60gb OCZ Solid Series 2 in RAID0


3x Dell 2209wa in Eyefinity @ 3150x1680
February 4, 2010 10:00:35 PM

Looks like a very solid build!!

I love the three monitor layout on your desk.... makes me want to look at a mutiple monitor setup but that means a new desk and wife won't go for that... Now, you need to take some pics of your PC case for all to see what the insides look like!!
m
0
l
February 5, 2010 3:40:01 PM

Freakin awsum build dude
m
0
l
Related resources
February 5, 2010 11:24:20 PM

All I can say is...H^&%s Yeah!!!
m
0
l
February 6, 2010 10:09:17 AM

Here's the pc itself. Not quite finished, and you can see the exhaust fan sitting on my megahalems. Still waiting on newegg...



30 second fraps clip of Mass Effect 2:

http://www.youtube.com/watch?v=HsBWKvr1wLA

Sorry for the quality, not exactly a video converting/youtube pro.
