Now I need help with choosing right video card

Last response: in Graphics & Displays
Share
November 10, 2012 3:16:30 AM

so my power supply is 300 watts. I was told to get a hd 7750 and someone else said consider hd 7770. would getting 7770 be okay and not hurt my 300 watt power supply? Also, when I go to this site

http://www.amd.com/us/products/desktop/graphics/7000/77...

there are various types for 7750 and 7770. how do i pick the right one? for example, i don't understand difference between power color radeon hd 7770 1024mb vs a 1gb dr2. i would like the best one my computer can handle. also, would amd be the cheapest/best since i don't wanna spend too much. a little over $100 at most.

finally, would upgrading this video card allow me to play assassin's creed without lag and bad pixels? i downloaded the game today and the mouse moved slow and lagged like hell.

i also would like to know if i'd be able to play future games that come out for years to come. thank you


System Model: Inspiron 620

Processor: Intel(R) Core(TM) i3-2120 CPU @ 3.30GHz (4 CPUs), ~3.3GHz
Memory: 6144MB RAM
Available OS Memory: 6056MB RAM
Page File: 3034MB used, 9077MB available
Windows Dir: C:\Windows
DirectX Version: DirectX 11
DX Setup Parameters: Not found

---------------
Card name: Intel(R) HD Graphics Family
Manufacturer: Intel Corporation
Chip type: Intel(R) HD Graphics Family
DAC type: Internal

Display Memory: 1696 MB
Dedicated Memory: 64 MB
Shared Memory: 1632 MB
Current Mode: 1920 x 1080 (32 bit) (60Hz)
Monitor Name: HP 2511 Series Wide LCD Monitor
Monitor Model: HP 2511
Monitor Id: HWP293F
Native Mode: 1920 x 1080(p) (60.000Hz)

More about : choosing video card

a c 166 U Graphics card
a b ) Power supply
November 10, 2012 3:24:55 AM

No you would not, those cards are not amazing at 1920x1080. They can barely pay current games at that resolution.

But since your PSU is limiting you, get the HD 7750 to be on the safe side. A 7770 would strain it to much.
m
0
l
a b U Graphics card
November 10, 2012 3:50:26 AM

Novuake said:
No you would not, those cards are not amazing at 1920x1080. They can barely pay current games at that resolution.

But since your PSU is limiting you, get the HD 7750 to be on the safe side. A 7770 would strain it to much.



Wrong. A 7750 is pretty impressive. You could easily play assasins creed at 1080p at decent settings. Maybe even maxed out. As for which one to get; get the cheapest one lol. The are all basically the same.

P.S. here is a benchmark of a 7750 running BF3 on high at 35 FPS. If it can do that, ACIII is a walk in the park!

http://www.tomshardware.com/reviews/radeon-hd-7770-7750...
m
0
l
Related resources
a c 87 U Graphics card
a b ) Power supply
November 10, 2012 4:11:09 AM

7750s are not all basically the same. Performance varies between some models greatly. For example, the DDR3 version barely beats a Radeon 6670 and even among the GDDR5 versions, the clock frequencies on the GPU and memory can vary quite a bit from 800MHz on the GPU to at least 900MHz and from 1125MHz on the GDDR5 memory to at least 1200MHz. The fastest GDDR5 versions can be as much as about 15-20% faster than the reference0clocked GDDR5 models, the DDR3 versions all have a little over half of the reference GDDR5 verson's performance.

There is slightly more variance between some different 7770s than there is between the GDDR5 7750 cards.

We can't make an accurate recommendation based on power requirements without more information on your PSU. What model is it? If you can't tell us the model, can you at least give us the amperage rating of each rail (this information will be on a sticker on the PSU inside the computer's case)?
m
0
l
a b U Graphics card
November 10, 2012 4:21:41 AM

blazorthon said:
7750s are not all basically the same. Performance varies between some models greatly. For example, the DDR3 version barely beats a Radeon 6670 and even among the GDDR5 versions, the clock frequencies on the GPU and memory can vary quite a bit from 800MHz on the GPU to at least 900MHz and from 1125MHz on the GDDR5 memory to at least 1200MHz. The fastest GDDR5 versions can be as much as about 15-20% faster than the reference0clocked GDDR5 models, the DDR3 versions all have a little over half of the reference GDDR5 verson's performance.

There is slightly more variance between some different 7770s than there is between the GDDR5 7750 cards.

We can't make an accurate recommendation based on power requirements without more information on your PSU. What model is it? If you can't tell us the model, can you at least give us the amperage rating of each rail (this information will be on a sticker on the PSU inside the computer's case)?


Hey calm down man. I had no idea there is a DDR3 version (Who the f%$k would do that?). Obviously get the cheapest DDR5 you can.
m
0
l
a c 87 U Graphics card
a b ) Power supply
November 10, 2012 4:34:29 AM

CaptainTom said:
Hey calm down man. I had no idea there is a DDR3 version (Who the f%$k would do that?). Obviously get the cheapest DDR5 you can.


There are three Radeon 7750 DDR3 models at Newegg, one PowerColor, one MSI, and one HIS.

It's GDDR5.

Why just the cheapest? A few bucks more can get noticeable performance improvements.

Even better, if OP's PSU can handle a 7770, is the fact that 7770s are going for about the same price as 7750s, making any 7750 a poor buy unless you can't power the 7770 or don't want a significant performance boost.
m
0
l
a c 166 U Graphics card
a b ) Power supply
November 10, 2012 4:46:50 AM

CaptainTom said:
Wrong. A 7750 is pretty impressive. You could easily play assasins creed at 1080p at decent settings. Maybe even maxed out. As for which one to get; get the cheapest one lol. The are all basically the same.

P.S. here is a benchmark of a 7750 running BF3 on high at 35 FPS. If it can do that, ACIII is a walk in the park!

http://www.tomshardware.com/reviews/radeon-hd-7770-7750...


Keep in mind that 35 FPS is AVERAGE FPS. As soon as that drops below 30 you can notice and feel it. And it will happen often!

Don't get me wrong, its an AMAZING card for what it was made for(HTPC and the like), consider it can draw all power needed via the PCI-e port.
m
0
l
a c 87 U Graphics card
a b ) Power supply
November 10, 2012 5:08:01 AM

Novuake said:
Keep in mind that 35 FPS is AVERAGE FPS. As soon as that drops below 30 you can notice and feel it. And it will happen often!

Don't get me wrong, its an AMAZING card for what it was made for(HTPC and the like), consider it can draw all power needed via the PCI-e port.


So drop a few settings, problem solved. Even a Radeon 6750 can game at 1080p with lowered settings just fine, so a much faster 7750 or even better, 7770, shouldn't have any problem with it, especially with current drivers. Current drivers compared to the drivers used in February can increase performance dramatically, especially in BF3.

Also, the 7750 is way too high end and expensive to be worth putting in an HTPC. A far cheaper Radeon 6450 or 6570 can do that job just as well and the 6450 even uses less power than the 7750 (the 6570 uses slightly more power, but is still much cheaper up front).
m
0
l
a c 166 U Graphics card
a b ) Power supply
November 10, 2012 5:18:44 AM

blazorthon said:
So drop a few settings, problem solved. Even a Radeon 6750 can game at 1080p with lowered settings just fine, so a much faster 7750 or even better, 7770, shouldn't have any problem with it, especially with current drivers. Current drivers compared to the drivers used in February can increase performance dramatically, especially in BF3.

Also, the 7750 is way too high end and expensive to be worth putting in an HTPC. A far cheaper Radeon 6450 or 6570 can do that job just as well and the 6450 even uses less power than the 7750 (the 6570 uses slightly more power, but is still much cheaper up front).
\

LOL with that mentality you may as well use Intel HD4000 graphics.

Let me say it again. You can not expect to reliably game at HD resolution with a HD7750. It would be outdated too soon.

That benchmark you linked is for one segment in the Single player campaign. Trust me when I say when tanks and planes start shooting, it will not keep 35 average FPS, not even close...
m
0
l
a b U Graphics card
November 10, 2012 5:19:57 AM

blazorthon said:
There are three Radeon 7750 DDR3 models at Newegg, one PowerColor, one MSI, and one HIS.

It's GDDR5.

Why just the cheapest? A few bucks more can get noticeable performance improvements.

Even better, if OP's PSU can handle a 7770, is the fact that 7770s are going for about the same price as 7750s, making any 7750 a poor buy unless you can't power the 7770 or don't want a significant performance boost.


Let's be honest here how much more power will you get? Will a $110 7750 perform 10% better than a $100 one? Hell no! If you want to spend more money, get a different card lol. Also yes a 7770 is a great deal right now!
m
0
l
a b U Graphics card
November 10, 2012 5:22:27 AM

Novuake said:
\

LOL with that mentality you may as well use Intel HD4000 graphics.

Let me say it again. You can not expect to reliably game at HD resolution with a HD7750. It would be outdated too soon.

That benchmark you linked is for one segment in the Single player campaign. Trust me when I say when tanks and planes start shooting, it will not keep 35 average FPS, not even close...


That is before the driver update that made it even better, and like the other guy said YOU CAN LOWER SETTINGS. I guarantee it would be fine on medium. Also who cares if it briefly drops to 20-25 FPS? That's quite playable as long as it is brief (And doesn't go lower).
m
0
l
a c 166 U Graphics card
a b ) Power supply
November 10, 2012 5:26:34 AM

CaptainTom said:
Let's be honest here how much more power will you get? Will a $110 7750 perform 10% better than a $100 one? Hell no! If you want to spend more money, get a different card lol. Also yes a 7770 is a great deal right now!


Are you sure his 300watt PSU can run the 7770? I would also suggest that card but you can't suggest it if you do not know.
m
0
l
a c 87 U Graphics card
a b ) Power supply
November 10, 2012 5:37:30 AM

Novuake said:
\

LOL with that mentality you may as well use Intel HD4000 graphics.

Let me say it again. You can not expect to reliably game at HD resolution with a HD7750. It would be outdated too soon.

That benchmark you linked is for one segment in the Single player campaign. Trust me when I say when tanks and planes start shooting, it will not keep 35 average FPS, not even close...


That's just stupid. Playing at just below maxed settings is the whole point of entry level 1080p gaming. You're taking it to an irrelevant extreme. Dropping settings slightly is nothing like dropping them to minimums like you'd need to do just to hope to play with HD 4000.

multi-player gaming inhibits the CPU far more than the GPU compared to single player.
m
0
l
a c 87 U Graphics card
a b ) Power supply
November 10, 2012 5:38:13 AM

Novuake said:
Are you sure his 300watt PSU can run the 7770? I would also suggest that card but you can't suggest it if you do not know.


You can suggest it, you simply shouldn't outright recommend it. Suggesting it as a possibility is not bad just because we haven't confirmed it as an option, although recommending it would be premature.
m
0
l
a b U Graphics card
November 10, 2012 6:17:20 AM

Novuake said:
Are you sure his 300watt PSU can run the 7770? I would also suggest that card but you can't suggest it if you do not know.


A i3-2120 uses 65w, a 7770 uses 85w, and that still leaves 160w. That would be fine I think. Unless it was the worst of worst PSU's. But if its a DELL or HP it should be fine enough.
m
0
l
November 10, 2012 10:34:01 AM


Operating System: Windows 7 Home Premium 64-bit
Language: English (Regional Setting: English)
System Manufacturer: Dell Inc.
System Model: Inspiron 620

Processor: Intel(R) Core(TM) i3-2120 CPU @ 3.30GHz (4 CPUs), ~3.3GHz
Memory: 6144MB RAM
Available OS Memory: 6056MB RAM
Page File: 3034MB used, 9077MB available
Windows Dir: C:\Windows
DirectX Version: DirectX 11
DX Setup Parameters: Not found

---------------
Card name: Intel(R) HD Graphics Family
Manufacturer: Intel Corporation
Chip type: Intel(R) HD Graphics Family
DAC type: Internal

Display Memory: 1696 MB
Dedicated Memory: 64 MB
Shared Memory: 1632 MB
Current Mode: 1920 x 1080 (32 bit) (60Hz)
Monitor Name: HP 2511 Series Wide LCD Monitor
Monitor Model: HP 2511
Monitor Id: HWP293F
Native Mode: 1920 x 1080(p) (60.000Hz)
m
0
l
November 10, 2012 11:05:42 AM

hey, thanks guys. I will have to open my pc up tonight as soon as I get the right screwdriver so I can tell you the Rail Amperage.

m
0
l
November 10, 2012 11:06:59 AM

btw, if i'm planning to hook up my stereo speakers to my pc, won't that raise my wattage use level and go over the 300 watt limit?
m
0
l
a c 87 U Graphics card
a b ) Power supply
November 10, 2012 11:12:43 AM

I doubt that stereo speakers will use much power from the PC, but that's me.
m
0
l
November 10, 2012 11:54:38 AM

okay, and one more question before i go to work. so in a few years, when better graphics cards come out.... will i need a more wattage power supply or will technology actually reduce the amount of power supply wattage needed as new cards come out b/c i feel like i'm at my limit with the 300 and i will have to buy a whole new pc in a year or two. I'm hoping to just switch out a graphics card at least once before i get a new pc and upgrade to better core processor. thanks
m
0
l
a c 291 U Graphics card
a b ) Power supply
November 10, 2012 11:58:49 AM

Well, nobody knows what nvidia and AMD have in mind. The current trend is that power consumption of the graphics cards is dropping. Also, you can always upgrade the power supply unit :) .
m
0
l
a c 166 U Graphics card
a b ) Power supply
November 10, 2012 3:13:01 PM

chinesepug said:
btw, if i'm planning to hook up my stereo speakers to my pc, won't that raise my wattage use level and go over the 300 watt limit?


Stereo speakers will will use almost zero power on your system. They usually have an added power source.

Yes at the moment power consumption is going down dramaticly PER PERFORMANCE. They don't really just go down. Only from what they can perform with given power.

I think you will have to upgrade your PSU in the future anyway.
m
0
l
November 10, 2012 11:49:51 PM

thanks guys. Hey blazothorn, i have to get screw driver to pull apart my computer and tell you the details of my power supply, so I'll let you know by tomorrow early afternoon or whenever you see this post.

m
0
l
a c 87 U Graphics card
a b ) Power supply
November 11, 2012 12:02:19 AM

OK then.
m
0
l
November 11, 2012 12:06:54 AM

also, blazothorn. do you have any recommendations for a power supply? would something like this work?

http://www.newegg.com/Product/Product.aspx?Item=N82E168...

some guy was recommended this b/c he also had 300 watt power supply. do you have any recommendations on a quality/cheap power supply i could buy?
m
0
l
November 11, 2012 12:11:20 AM

nvm. let's just wait for my results. i'm just paranoid b/c i've been researching and some people are saying don't risk it and that inefficiency adds to wattage usage as well.
m
0
l
a c 87 U Graphics card
a b ) Power supply
November 11, 2012 12:11:23 AM

http://pcpartpicker.com/part/antec-power-supply-vp350

Dirt cheap at just over $23, yet one of the highest quality power supplies that most people would ever see. This model should do the trick for you excellently and inexpensively should your power supply prove to be inadequate.
m
0
l
November 11, 2012 4:27:48 AM

just spoke with dell cause damn screw drivers wouldn't fit. i'll have to buy one tomorrow. he also said it's one of these three brands light tone

deata
hunmtkey

he said that all have same specs. once i open my damn comp, i can tell u for sure.
m
0
l
a b U Graphics card
November 11, 2012 6:01:49 PM

chinesepug said:
just spoke with dell cause damn screw drivers wouldn't fit. i'll have to buy one tomorrow. he also said it's one of these three brands light tone

deata
hunmtkey

he said that all have same specs. once i open my damn comp, i can tell u for sure.


As long as it has a moled adapter you are fine man.
m
0
l
November 11, 2012 6:37:01 PM

input: 100-127v ~/9A
200-240v ~/4.5A
50-60 Hz

output: +5V: 13A max
+5Vaux: 2A max
-12V: .3A max

+12VA: 17A max
+12VB: 9A Max
+3.3V: 10A Max


looks like the power supply is made in china and has logo: c RU
m
0
l
November 11, 2012 6:38:35 PM

also, look like I have one slot left inside and I'm hoping to God that's it's a PCI slot for the video card that i want. i took a photo but can't upload it on here.
m
0
l
November 11, 2012 7:05:06 PM

looks like i do have one pct express slot. btw, is it me or did they raise the prices for the hd 7770 recently?
m
0
l
a c 166 U Graphics card
a b ) Power supply
November 11, 2012 7:07:41 PM

chinesepug said:
also, look like I have one slot left inside and I'm hoping to God that's it's a PCI slot for the video card that i want. i took a photo but can't upload it on here.


Upload the PHOTO here and then link it.

photobucket.com

It seems to me you will not have enough reliable power for and HD7770. A HD7750 will stress it enough.
m
0
l
November 11, 2012 7:19:33 PM

so you're saying that hd 7750 is perfect right? it won't stress it in a bad way. also, if i wanted to get a 350 watt power supply, how would i know if it would fit in my computer? is the one blzothorn recommended perfect size for my comp? will adding a higher wattage power supply require more cooling system b/c more heat will be created? will my icore 3 be able to handle a bigger power supply and hd 7770 card strain/stress?
m
0
l
November 11, 2012 7:42:07 PM

also, my computer is pretty quiet, so will adding more power supply wattage and a powerful video card make my whole system run louder and harder? and should i wait for black friday or electronics day or when 2012 ends to wait for a cheaper price? thanks
m
0
l
a c 166 U Graphics card
a b ) Power supply
November 11, 2012 7:53:59 PM

chinesepug said:
so you're saying that hd 7750 is perfect right? it won't stress it in a bad way. also, if i wanted to get a 350 watt power supply, how would i know if it would fit in my computer? is the one blzothorn recommended perfect size for my comp? will adding a higher wattage power supply require more cooling system b/c more heat will be created? will my icore 3 be able to handle a bigger power supply and hd 7770 card strain/stress?


Yes I am saying for your system to be on the safe side, stick to HD7750, might not be very powerful but its safer.

IF you decide to upgrade your PSU, rather do it properly and get atleast a 550W, that would give you some upgrade room.

No a higher wattage PSU would not require better cooling and would probably lessen the noise if you got a good unit.

A graphics card of that size(HD7750 and HD7750) are very quiet and would add very little noise to your PC.

PSU sizes that you should by is any standar ATX psu(most that you could easily get ahold of are ATX. Your case is fine for the HD7770 or HD7750 and the suggested PSU, even a higher wattage one will fit fine.

Oh and yes that is a PCI-e port for a graphics card.
m
0
l
November 11, 2012 10:00:09 PM

okay, thanks. i'm thinking about getting this:

http://www.microcenter.com/product/387845/H777F1G2M_iCo...

if I upgrade to a 550W PSU, will i be able to put a even more powerful card than a hd 7770? If so, what would the most powerful card I could use on a 550W? How do you measure that, is there a site that tells you that?

also, if i get a 550w PSU, with an awesome video card but i still have a ntel(R) Core(TM) i3-2120 CPU @ 3.30GHz, my video card won't work at its best right?

I guess what i'm asking is what are the biggest hardware components that affects the usability/efficiency of a video card and is there a site for that?

it's like i get a better power supply and video card but i have no clue if the rest of my computer will able to even run the card properly.
m
0
l

Best solution

a c 166 U Graphics card
a b ) Power supply
November 11, 2012 11:11:21 PM

We suggest the HD7750 because it doesn't really require a 400W PSU. It doesn't even have a power plug needed from the PSU. It draws from the board only.

If you happen to add a 550W good unit you could run a HD7950 no issues. And not you wouldn't really be held back by your CPU except in games like skyrim or Battlefield 3 maps that are huge.

http://microcenter.com/product/385360/11202-00-20G_Rade...

That is of a better brand and its cheaper. Only get that if you are keeping your current PSU, if not get the best your budget can allow.

Unfortunately there is no such site.
Share
November 11, 2012 11:18:51 PM

Go with the 7750. The difference to 7770 is less than 20%, and its much safer. You will be pushing the PSU if you go with the 7770, it might cause instabilities even if you dont go past the 300W limit.
m
0
l
November 12, 2012 2:20:17 AM

Best answer selected by chinesepug.
m
0
l
November 12, 2012 2:21:14 AM

thanks alot guys. appreciat it
m
0
l
!
