Intel Z87 Desktop Board DZ87KLT-75K Spotted

By - Source: eTeknix | B 23 comments

Some images and details have surfaced regarding one of Intel's upcoming Desktop Boards.

Image Source: eTeknixImage Source: eTeknixThe folks over at eTeknix have given us a sneak-peak at Intel's upcoming DZ87KLT-75K motherboard. This is a Z87-based motherboard that is ready to be used with the upcoming fourth generation of Intel Core-i Series processors. The motherboard features an 8-phase VRM design, which fuels the CPU and draws its power from a single 8-pin EPS connector.

Image Source: eTeknixImage Source: eTeknixThe board features room for up to four DDR3 memory banks, features a blue and black design, and has a total of four 4-pin PWM fan headers.

Expansion is handled by three PCIe 3.0 x16 slots, another three PCIe x1 slots, and a legacy PCi slot. Storage comes in the form of eight SATA3 ports, six through the Z87 chipset and another two through a third party controller. In addition, there is also a mini-PCIe slot which can also function as an mSATA slot. Rear I/O connectivity is taken care of by six USB 3.0 ports, one 800 Mb/s FireWire port, two Gigabit Ethernet ports, 7.1 channel HD analog audio, Optical SPDIF out, and a first-gen Thunderbolt port which also works as a mini-DisplayPort. A separate model, the DZ87KL-70K, will not feature the Thunderbolt port -- the port will just work as a mini-DisplayPort.Image Source: eTeknixImage Source: eTeknix

It is likely, though, that this will be one of the last motherboards that Intel produces, since Intel announced that it will be leaving the design and manufacturing of desktop motherboards.
