Silverstone Cases Promise Improved Air-flow with Fewer Fans

By , Andrea Ferrario - Source: Tom's Hardware US | B 18 comments

We saw a lot of weird cases at Computex, but there was also a ton of more conventional looking cases that focused more on function than form. Silverstone had two such cases at its booth, the Raven 4 and the FT04.

The Raven 4 is a plastic case fitted with a "Hi-Flow air filter" that Silverstone maximizes airflow, offering improvements of up to 30 compared to previous solutions, and improved dust buster capabilities. Silverstone has removed the rear grill to improve air flow and these two differences help Silverstone reach the same cooling performance of the previous model with one fewer fan. The FT04 is the same case but it's fashioned out of aluminum as opposed to plastic.

Silverstone also had on hand a new mini-PC called the SG-09 with a 23 liter capacity as well as a micro-ATX motherboard, a standard PSU, space for two HDDs and four SSDs, two fans, standard length VGA cards, and two USB 3.0 ports on the front.

The Raven 4 will be available in Q4 priced at €130, while the aluminum FT04 will cost €180/€200 (also available in Q4).

Follow @JaneMcEntegart on Twitter.

Discuss
Ask a Category Expert

Create a new thread in the News comments forum about this subject

Example: Notebook, Android, SSD hard drive

This thread is closed for comments
Top Comments
  • 17 Hide
    luke738 , June 9, 2012 2:14 AM
    "improvements of up to 30"

    May want to add a unit there...
Other Comments
  • -7 Hide
    erunion , June 9, 2012 1:14 AM
    "Silverstone also had on hand a new mini-PC called the SG-09 with a 23 liter capacity'

    That must be a typo. Anyone think they can fit 23 1 liter bottles in their case?
  • 5 Hide
    JohnnyLucky , June 9, 2012 1:42 AM
    "Silverstone has removed the rear grill to improve air flow"

    About time one of the case manufacturers did that. I've been removing fan guards, perforated mesh, and grills from the rear panel for years. Improves hot air exhaust, especially if an exhaust fan on the rear panel is aligned with cpu heatsink fans.

    Might not be such a good idea if you have curious cats and little children.
  • Display all 18 comments.
  • 2 Hide
    nikorr , June 9, 2012 1:54 AM
    Quote:
    "Silverstone has removed the rear grill to improve air flow"

    About time one of the case manufacturers did that. I've been removing fan guards, perforated mesh, and grills from the rear panel for years. Improves hot air exhaust, especially if an exhaust fan on the rear panel is aligned with cpu heatsink fans.

    Might not be such a good idea if you have curious cats and little children.

    Thank god for the Dremel :D

  • 3 Hide
    A Bad Day , June 9, 2012 2:00 AM
    JohnnyLucky"Silverstone has removed the rear grill to improve air flow"About time one of the case manufacturers did that. I've been removing fan guards, perforated mesh, and grills from the rear panel for years. Improves hot air exhaust, especially if an exhaust fan on the rear panel is aligned with cpu heatsink fans.Might not be such a good idea if you have curious cats and little children.


    Well, you could put the case in a large chicken-wire box. Very minimal airflow disruption while keeping paws and hands away from the fans.
  • -5 Hide
    A Bad Day , June 9, 2012 2:04 AM
    JohnnyLucky"Silverstone has removed the rear grill to improve air flow"About time one of the case manufacturers did that. I've been removing fan guards, perforated mesh, and grills from the rear panel for years. Improves hot air exhaust, especially if an exhaust fan on the rear panel is aligned with cpu heatsink fans.Might not be such a good idea if you have curious cats and little children.


    You could encase the tower with a large chicken wire box. Does a handy job of keeping out paws and hands with little airflow disruption.
  • 17 Hide
    luke738 , June 9, 2012 2:14 AM
    "improvements of up to 30"

    May want to add a unit there...
  • 6 Hide
    skaz , June 9, 2012 2:51 AM
    more pictures please =).
  • 2 Hide
    SpicPeso , June 9, 2012 2:57 AM
    Am I the only one that is disappointed to see Silverstone straying away from what made the Raven cases so special and well performing in the first place, their vertical orientation? The new Raven looks nothing more than any other run-of-mill enthusiast case now. And as luke738 stated before, "improvements of up to 30" what I can only assume %, they are going to have to show me hard numbers before I believe that case is better than any other case, but more importantly, that it is a worthy successor to the Raven 3. Now that was a badass tower.
  • 6 Hide
    pocketdrummer , June 9, 2012 4:17 AM
    Why bother marketing the FT04 as an "aluminum" case when there's more plastic there than aluminum? Silverstone started off as a decent alternative to Lian li if you wanted an Aluminum case, now they're just expensive cases that offer nothing more than any other case manufacturer out there. They're butt ugly and the design is uninspired and overcomplicated.

    Just make the FT03 ENTIRELY aluminum and call it a day. Until then, I'm keeping my Lian Li.
  • 0 Hide
    Travis Beane , June 9, 2012 7:05 AM
    I have an old Silverstone KL01, and I absolutely love it. I would love it even more if it was larger (wasn't big enough for my needs). It's solid vd extremely heavy.

    I require a heavy steel case, and I require that there be absolutely no fragile plastic components. It must be stiff, indestructible, well ventilated and preferably easy access with hot swap bays.
  • -2 Hide
    Anonymous , June 9, 2012 9:59 AM
    Well duh, its a BTX case. that is what BTX was designed for. BTX was made for better airflow for the Pentium D series because those CPUs run very very hot. The Pentium D was the Prescott P4 but put 2 Dies on one chip and link them together to make a dual core. Hottest CPUs ever Made.
  • 3 Hide
    Pyree , June 9, 2012 10:11 AM
    erunion"Silverstone also had on hand a new mini-PC called the SG-09 with a 23 liter capacity'That must be a typo. Anyone think they can fit 23 1 liter bottles in their case?

    If you do a bit of maths, you will notice that 23 litre is not that big. It is smaller than 20x30x40cm.
  • 2 Hide
    Pyree , June 9, 2012 10:15 AM
    wearlWell duh, its a BTX case. that is what BTX was designed for. BTX was made for better airflow for the Pentium D series because those CPUs run very very hot. The Pentium D was the Prescott P4 but put 2 Dies on one chip and link them together to make a dual core. Hottest CPUs ever Made.

    Actually, they are EATX cases.
  • 4 Hide
    CaedenV , June 9, 2012 11:09 AM
    wearlWell duh, its a BTX case. that is what BTX was designed for. BTX was made for better airflow for the Pentium D series because those CPUs run very very hot. The Pentium D was the Prescott P4 but put 2 Dies on one chip and link them together to make a dual core. Hottest CPUs ever Made.

    BTX (unfortunately in my opinion) died with the PD processors. It was not only an alignment of the case fans with the mobo fans, it also put the cpu, northbridge, and card slots in a line so that all of your major heat generating components were able to get maximum airflow. Things like ram, headers and rear IO shield were moved to the top of the board for easier access to fat fingers like mine. Power supplies and disc drives also made a line at either the top or bottom of the case for easier cooling as well (most power supplies used in BTX cases had a fan on the front/back of the supply instead of the bottom of the supply like we see today). Lastly BTX cases were mounted on the left side of the case instead of the right. I'm not sure though if that was part of the standard, or if that was just the popular way to do it to visually differentiate themselves from 90% of the ATX cases out there.
    This is just an EATX case that takes an ATX mobo and better aligns the fans and the case while mounting it 'upside down' on the left side of the case. Still a good case, but hardly groundbreaking compared to other offerings available today.

    BTX is not needed today for the sake of heat dissipation, but I would love to see it come back for the sake of visual appeal. The bulk of the headers and connectors are on the top of the board, instead of just everywhere like they are on ATX. Most GPUs and other ad-on cards have some amount of artwork on the right side of the card... which normally faces down in an ATX case, and makes it harder to see. In a BTX (or left mounted case in general) such artwork faces up where you can see it. Also, by facing up the heat is better drawn away from the card. Having all of your interesting components (cpu, gpu, and mobo heat spreaders for mosfets and northbridge) in a line also means you can do easier and more interesting lighting, or smaller windows that still show off your stuff. I don't know, maybe it is a form factor that is an electrical engineer's nightmare, but it seemed like a step forward to me, and I was sad to see it die off.
  • 1 Hide
    joshyboy82 , June 9, 2012 12:19 PM
    "Up to 30". That means nothing with out a unit of measurement, which wasn't given up to that point. Thanks Big Guy, you're still my special little friend.
  • 1 Hide
    11796pcs , June 10, 2012 12:20 AM
    I absolutely adore my Silverstone RV02B-EW case that I bought, Silverstone keep up the good work! The 90 degree ATX turn that they use is brilliant and helps with long, heavy graphics cards.
  • 1 Hide
    kendrose , June 10, 2012 5:32 PM
    Quote:
    Why bother marketing the FT04 as an "aluminum" case when there's more plastic there than aluminum? Silverstone started off as a decent alternative to Lian li if you wanted an Aluminum case, now they're just expensive cases that offer nothing more than any other case manufacturer out there. They're butt ugly and the design is uninspired and overcomplicated.

    Just make the FT03 ENTIRELY aluminum and call it a day. Until then, I'm keeping my Lian Li.



    Right there with you. Lian Li is one of the few case mfg that dont make over the top gaudy crap. It seems that all the high end cases look like a neon strip club from the 60/70s. My desktop and HTPC are both Lian Li. The computer I built for my parents (and the office we run our busness out of), Lian Li. The CAD workstation I am building my aunt for her interior design, Lian Li. Ill pay a little extra to get the solid aluminum, and vibration isolation excesories. They are quiet, effictive, and they have nice clean look. And those of you who dont want plastic parts, the only thing on the lian li that could use an upgrade are the tool less clips for the 5.25 bays. Those are plastic. But I just use screws old school style.
  • 0 Hide
    tomhuang03 , June 28, 2012 11:02 AM
    Looks made of pretty flimsy plastic.
