We chose a Core 2 Duo Mobile processor, the T7600, for our testing to observe what kinds of noise levels a desktop built around this type of processor would manifest. Asus deliberately designed this motherboard for use in low-power, low-noise applications, and our prior experience with this component showed it to be at least an adequate performer and indeed both quiet and with relatively modest power demands.
| Asus N4L-VM DH | |
|---|---|
| Northbridge | Intel 945 GM (MCH) |
| Southbridge | Intel ICH7-M (DH) |
| Voltage Regulator | Six Phases |
| BIOS | AMI 0502 (04/03/2007) |
| 266.7 MHz (FSB667) | 266.7 MHz (+0.0%) |
| Connectors and Interfaces | |
| Onboard | 1x PCIe x16
1x PCIe x1 2x PCI 2x USB 2.0 (2 ports per connector) 1x COM 1x Printer 1x TV out 1x Floppy 1x Ultra ATA 4x Serial ATA 3.0Gb/s 1x Front Panel Audio 1x S/P-DIF In/Out 1x IEEE-1394 FireWire 1x Fan 4 pins (CPU) 1x Fan 3 pins (Chassis) 1x Clear CMOS Jumper |
| IO panel | 2x PS2 (keyboard + mouse)
1x RJ-45 Network 4x USB 2.0 1x IEE1394a port 1x eSATA port 1x optical S/PDIF output 1x coaxial S/PDIF output 1x DVI-D 1x VGA Out 8x Analog Audio (7.1 Channel, Mic-In, Line-In) |
| Mass Storage Controllers | |
| ICH-7M (DH) | 2 x SATA 1.5 Gb/s (RAID 0,1,Matrix)
1x Ultra ATA-100 (2-drives) |
| JMicron SATA Controller | 1x Internal SATA 3.0 GB/s (RAID 0,1)
1x eSATA 3.0 Gb/s (RAID 0,1) |
| Network | |
| GbE LAN controller | Intel 82573L |
| Audio | |
| HDA (Azalia) Controller Interface | Realtek ALC882M 7.1 Codec |
| FireWire | |
| TI TSB43AB22A | 2x IEEE-1394a (400 Mb/s) |
| Graphics | |
| Integrated graphics | Intel Graphics GMA 950 |
| Memory | |
| Dual channel
2x 240-pin DIMM |
Up to 2 GB of unbuffered 667/533 DDR2 |
The N4L-VM conforms to Intel ViiV specifications, which means it works especially well with Windows MCE and Windows Vista Home Premium and Ultimate editions. It's built around the Intel 945GM and ICH7M-DH chipsets. Retail pricing on this motherboard runs from $100 to $145. Its built-in graphics would be okay for regular office applications, but for games or media, you'd want to follow our lead in this build and use a PCI-e x16 graphics card (we chose a passively cooled Gigabyte GeForce 8600 GTS model to bring graphics performance as high as possible).
| T7600 System Hardware | |
|---|---|
| Socket 479 Processor | Intel Core 2 Duo Mobile T7600
(Merom 65 nm, 2.33 GHz, 4 MB L2 Cache) |
| RAM | Corsair Dominator TWIN2X2048-8500C5D
2x 1024 MB DDR2-1066 (CL 5.0-5-5-15) |
| Hard Drive | 2x Seagate 7200.10 ST3320620AS 320 GB, 7,200 RPM, 16 MB Cache, SATA/300 |
| Graphics Card | Gigabyte GV- NX86S256H GeForce 8600 GTS SilentPipe 3 - 256 MB |
| Power Supply | Corsair CMPSU-450VX 450W power supply |
| System Software & Drivers | |
| OS | Windows XP Professional Media Center Edition 2005 Build 5.10.2600, Service Pack 2 |
| DirectX Version | 9.0c (4.09.0000.0904) |
| Platform Drivers | Intel Platform: INF 8.3.0.1013 |
| Graphics Driver | Forceware 162.18 |
