Four Closed-Loop CPU Coolers Take On Noctua's NH-D14

Four Closed-Loop CPU Coolers Take On Noctua's NH-D14
By

Closed-loop liquid coolers relieve stress from our motherboards, without the portability and maintenance issues of traditional open-loop kits. Are these the best devices for system builders who plan to move their machines and want to avoid damage?

We know from experience that cooling performance is mostly tied to the size of your sink and the air moving over it. The folks selling heat sinks know this too, which helps explain how our most recent round-up of air coolers grew to 14 samples (Big Air: 14 LGA 2011-Compatible Coolers For Core i7-3000, Reviewed).

Anyone who's ever studied physics tends to get a little nervous when they see us supporting a couple pounds of copper and aluminum with a few inches of leverage over a delicate circuit board. Configurations that work marvelously on a system you build and leave at home are prone to failure when you move that machine around. Just think about the nightmare boutique builders face when it comes to mailing off an expensive system with an aggressively overclocked processor and multiple graphics cards inside.

Even we're affected by the problem of heavy heat sinks! We used to ship the winners of our System Builder Marathon giveaways fully-built PCs. Enough coolers broke loose (or broke motherboards) that we had to start taking them apart and boxing up the individual pieces first. Sometimes I'd experiment with water-cooling in my high-end SBM submission, and that was equally problematic when it came to shipping.

Fortunately, a more user-friendly form of cooling is available. Closed-loop liquid coolers rarely leak, they have no fill ports from which to spill, there is no separate pump or reservoir to break loose, and the small water blocks place little stress on the motherboard. Although they aren't as configurable as conventional water-cooling kits, sealed coolers boast superior portability, transportability, and maintainability.

The newest generation of closed-loop systems is even said to offer better performance than those that matched the air-cooling market a year ago. But heat sinks and fans continue evolving too, and there's a new sheriff in town. Are sealed liquid coolers really ready to stand up to a truly monstrous air cooler?

Closed-Loop Liquid Coolers
 Cooler Master
Seidon 240M
Corsair
H100i
Enermax
ELC240
Zalman
LQ320
Length10.7"10.9"10.6"5.9"
Width4.8"4.7"4.7"4.9"
Rad. Thickness1.0"1.0"1.3"2.0"
Cooling Fans2 x 120 x 25 mm2 x 120 x 25 mm2 x 120 x 25 mm1 x 120 x 25 mm
Total Thickness2.0"2.0"2.3"3.0"
Control TypeMotherboard Fan HeadersIntegrated/Auto,
Programmable
Motherboard Fan HeaderMotherboard Fan Headers
Weight34 Ounces36 Ounces34 Ounces36 Ounces
AMD Processor Interfaces
All AM2 to AM3+Clip-OnAll AM2 to AM3+All AM2 to AM3+
Intel Processor Interfaces
775, 1156/1155, 1366, 2011775, 1156/1155, 1366, 2011775, 1156/1155, 1366, 20111156/1155, 1366, 2011
Web Price$100$120$120$105


With four vendors ready to prove their worth, we needed only to find a suitable platform and high-capacity air cooler of similar cost.
