MoonBounce Malware Hides In Your BIOS Chip, Persists After Drive Formats

Kaspersky Labs discovers MoonBounce
(Image credit: Kaspersky Labs)

A new type of malware takes a decidedly more stealthy and hard-to-remove path into your OS — it hides in your BIOS chip and thus remains even after you reinstall your OS or format your hard drive.

Kaspersky has observed the growth of Unified Extensible Firmware Interface (UEFI) firmware malware threats since 2019, with most storing malware on the EFI System Partition of the PC's storage device. However, a sinister development has been spotted over the New Year with a new UEFI malware, detected by Kasperksy's firmware scanner logs, that implants malicious code into the motherboard's Serial Peripheral Interface (SPI) Flash. The security researchers have dubbed this flash-resident UEFI malware 'MoonBounce'.

MoonBounce isn't the first UEFI malware discovered in the wild that targets SPI flash. Kaspersky says that the likes of LoJax and MosaicRegressor came before it. However, MoonBounce shows "significant advancement, with a more complicated attack flow and greater technical sophistication." It also seems to have infected a machine remotely.

MoonBounce is undeniably clever in the way it gets into a system and makes itself hard to detect and dispose of. "The source of the infection starts with a set of hooks that intercept the execution of several functions in the EFI Boot Services Table," explains Kaspersky on its SecureList blog. The hooks are then used to divert function calls to the malicious shellcode that the attackers have appended to the CORE_DXE image. This, in turn, "sets up additional hooks in subsequent components of the boot chain, namely the Windows loader," said the security researchers. This allows the malware to be injected into an svchost.exe process when the computer boots into Windows.

Magic marker values replaced during execution within shellcodes in MoonBounce. (Image credit: Kaspersky Labs)

Transport Technology Company the Only Logged Attack so Far

Of course, Kaspersky was interested to see what the malware would do next. So, on an infected machine, the researchers observed the malware process try and access a URL to fetch the next stage payload and run it in memory. Interestingly, this part of the sophisticated attack didn't seem to go anywhere, so it wasn't possible to analyze any further steps in MoonBounce. Perhaps this malware was still in testing when it was spotted, and/or it is being held back for special purposes. In addition, the malware isn't file-based and does at least some of its operations only in memory, making it hard to see exactly what MoonBounce did on the single host PC on a company's network.

A single machine, owned by a transportation company, seems to be the only machine on Kaspersky's logs that has a MoonBounce infection in its SPI Flash. It isn't certain how the infection took place, but it is thought it was instigated remotely. That sole machine at a transport technology company seems to have spread non-UEFI malware implants to other machines on the network. With much of its work being file-less and memory resident only, it isn't easy to observe from this single sample.

Below, a flow chart breaks down how MoonBounce boots and deploys from the moment your UEFI PC is switched on, through Windows loading, and into being a usable but infected PC.

(Image credit: Kaspersky Labs)

APT41 Fingerprints Detected

Another important branch of the work done by security researchers like Kaspersky is looking into who is behind the malware that it discovers, what the purposes of the malware are, and what specific targets the malware is primed for.

Concerning MoonBounce, Kaspersky seems pretty certain that this malware is the product of APT41, "a threat actor that's been widely reported to be Chinese-speaking." In this case, the smoking gun is a "unique certificate" that the FBI has previously reported as signaling the use of APT41-owned infrastructure. APT41 has a history of supply chain attacks, so this is a continuation of a central thread of APT41's nefarious operations.

Safety Measures

To help avoid falling victim to MoonBounce or similar UEFI malware, Kaspersky suggests a number of measures. It recommends users keep their UEFI firmware updated directly from the manufacturer, verify that BootGuard is enabled where available, and enable Trust Platform Modules. Last but not least, it recommends a security solution that scans system firmware for issues so measures can be taken when UEFI malware is detected.
