New Raspberry Pi CM4 Industrial Panel Has 4G, Dual Ethernet and More
Edatec has released a new Raspberry Pi CM4-powered industrial panel, adding a few new features we’re excited about. The ED-HMI2120-101C is currently available at AliExpress for $269. It’s designed to use the Raspberry Pi CM4 while offering a selection of tools like a touchscreen and external port access.
Swipe to scroll horizontally
Spec
ED-HMI2120-101C
Main Board
Raspberry Pi CM4
Storage
MicroSD card slot, 4KB EEPROM, M.2 NVMe 2030 or 2242 SSD via B-key Socket
Display
10-Inch TFT LCD 1280 x 800px Display
Video Output
HDMI 2.0
Camera
8MP
Audio Output
5W Speakers, 3.5mm Audio Jack
Network
RJ45, RJ45 with PoE, WiFi, Bluetooth, 4G LTE, SMA Antenna Connector
USB
2x USB 2.0 Type-A, 5-pin USB 2.0 FPC connector, Micro USB 2.0 Port
Expansion
40-pin GPIO Header for Raspberry Pi CM4
One of the biggest changes is the addition of a second Ethernet port. The ED-HMI2120-101C has two RS485 jacks, one of which offers optional PoE. It also now has the option of wireless network connectivity via 4G LTE support. Storage-wise, users can now connect an M.2 NVMe SSD instead of relying on onboard memory and microSD cards.
Edatec has also expanded the support ED-HMI2120-101C has for DC input with a range between 9V and 36V. It’s capable of powering external peripherals, like a second LCD screen, with an output of 12V. You can connect up to three devices using these 12V DC outputs.
Software-wise, the ED-HMI2120-101C is designed to work with Raspberry Pi OS. A few additional drivers are necessary to make use of all the tools, modules and features that come with the panel.
If you find carrier boards like this interesting, you might also enjoy looking through our list of best Raspberry Pi projects for some inspiring ideas and use cases for the ED-HMI2120-101C.
