As Intel's 13th Generation Raptor Lake processors are at close range, more leaked benchmarks have emerged. On this occasion, hardware leaker Tum_Apisak has uncovered a couple of the chipmaker's non-K SKUs, including the Core i7-13700, Core i5-13500, and Core i5-13400.
The Core i7-13700 wields 16 cores and 24 threads. The 65W Raptor Lake chip has eight P-cores and eight E-cores, with the former reportedly running with a 2.1 GHz base clock. It's the same P-core base clock as the current Core i7-12700. The boost clock speed for the Core i7-13700 is currently unknown, but the current trend shows that it may be lower than its Alder Lake counterpart. However, the Core i7-13700 has four more E-cores than the Core i7-12700.
According to PassMark, the Core i7-13700 (4,347 CPU marks) delivered up to 3.3% higher single-threaded performance than the Core i9-12900K. Furthermore, compared to the Core i7-12700 (3,947 CPU marks), the Core i7-13700 showed a 10.1% improvement.
While the Core i7-13700 revealed strong single-threaded performance, the 65W chip couldn't contend in a multi-threaded scenario. The Core i9-12900K (41,403 CPU marks) outpaced the Core i7-13700 (34,431 CPU marks) by a 20.2% margin in multi-threaded workloads. From a generation-over-generation standpoint, the Core i7-13700 only offered 9.7% higher multi-threaded performance over the Core i7-12700 (31,388 CPU marks).
Intel Raptor Lake Non-K Specifications*
| Processor | Configuration | P-Core Base (GHz) | P-Core Boost (GHz) | TDP (W) |
|---|---|---|---|---|
| Core i7-13700 | 8P + 8E | 2.1 | ? | 65 |
| Core i7-12700 | 8P + 4E | 2.1 | 4.8 | 65 |
| Core i5-13500 | 6P + 8E | 2.5 | 4.5 | 65 |
| Core i5-12500 | 6P | 3.0 | 4.6 | 65 |
| Core i5-13400 | 6P + 8E | 2.5 | 4.1 | 65 |
| Core i5-12400 | 6P | 2.5 | 4.4 | 65 |
*Specifications are unconfirmed.
The Core i5-13500 and Core i5-13400 also surfaced in PassMark's database. Unfortunately, there weren't any available results for comparison. Regarding upgrades, the Core i5-13500 and Core i5-13400 possess eight E-cores, whereas the Core i5-12500 and Core i5-12400 lack them. The clock speeds, on the other hand, didn't exhibit any upgrades.
The Core i5-13500's P-cores appear to have a 500 MHz lower base clock than the Core i5-12500. In addition, the Raptor Lake chip also exhibited a 100 MHz lower boost clock. In the case of the Core i5-13400, the 14-core part reportedly retains the same 2.5 GHz base clock as the Core i5-12400. However, Intel seemingly shaved 300 MHz off the Core i5-13400's boost clock.
Get Tom's Hardware's best news and in-depth reviews, straight to your inbox.
Raptor Lake processors arrive with Intel's Raptor Cove cores, which we can consider to be an optimized version of Golden Cove. The next-generation chips retain the same Gracemont cores from Alder Lake but have double the amount of E-cores. Raptor Lake also flaunts bigger L2 and L3 caches. It's a long list of improvements, and it won't be long until we see just how much performance Raptor Lake can offer over Alder Lake, as the rumored reveal date is at the Intel Innovation 2022 event on September 28.
Zhiye Liu is a news editor, memory reviewer, and SSD tester at Tom’s Hardware. Although he loves everything that’s hardware, he has a soft spot for CPUs, GPUs, and RAM.
-
-Fran- "However, Intel seemingly shaved 300 MHz off the Core i5-13400's boost clock."Reply
That... Could actually be a tad bad for everyone looking for a good value gaming CPU.
Well, benchmarks will tell.
Regards. -
TerryLaze Reply
If these are just specs taken from a spec sheet, then the clocks are for the stated TDP and running all the cores including e-cores.-Fran- said:"However, Intel seemingly shaved 300 MHz off the Core i5-13400's boost clock."
That... Could actually be a tad bad for everyone looking for a good value gaming CPU.
Well, benchmarks will tell.
Regards.
Boost clocks on the p-cores should be the same if not better as previous benchmarks since no single benchmark ever was done at 65W... -
watzupken Reply
If you are looking at the base 65W TDP, you should be looking at the base clockspeed. While the max clockspeed is for single core, I believe the all core boost should be around 4Ghz, which is not achievable at 65W.TerryLaze said:If these are just specs taken from a spec sheet, then the clocks are for the stated TDP and running all the cores including e-cores.
Boost clocks on the p-cores should be the same if not better as previous benchmarks since no single benchmark ever was done at 65W... -
TerryLaze Reply
4Ghz for running what?! All core depends heavily on how heavy the load is.watzupken said:If you are looking at the base 65W TDP, you should be looking at the base clockspeed. While the max clockspeed is for single core, I believe the all core boost should be around 4Ghz, which is not achievable at 65W.
Cinebench will have a radically different all core clock from ghostwire tokyo.
And again, nobody ever in the last years benchmarked any high-end desktop CPU locked at 65W. -
watzupken Reply
I am not sure if an i7 12700 is considered high end enough. If so, see review below. Most reviewers don't do such review simply because it makes little sense to slap an i9 chip which is not cheap, and setting a hard limit at 65W.TerryLaze said:4Ghz for running what?! All core depends heavily on how heavy the load is.
Cinebench will have a radically different all core clock from ghostwire tokyo.
And again, nobody ever in the last years benchmarked any high-end desktop CPU locked at 65W.
Intel Core i7-12700 + Intel B660 Review | TechSpot
In my opinion, all core turbo really means all cores at 100%. Games is more like a few cores are running at max speed, and some at half clockspeed with load bouncing between cores. And since the thread director in Windows 11 is meant to use the P-cores exclusively for games, so the E-cores are also generally in a very light state of usage just running background tasks. -
TerryLaze Reply
How did turbo come into play now?!watzupken said:In my opinion, all core turbo really means all cores at 100%.
Intel, and AMD as well for that matter, only provide you with base clock for base TDP, anything above (or below) that depends on what you run so nobody makes any real claims, they give you single core max boost and that's it, everything else is up to the user.
Since these will have more cores, even if they are e-cores, the base clocks for base TDP will be lower but if you run the same game/app on the same amount of p-cores excluding the e-cores the boost should be the same, if not better, compared to previous models.
That's why I asked you what software you expect 4Ghz on, because every one will boost differently.
