Understanding WPA/WPA2: Hashes, Salting, And Transformations

Wi-Fi Security: Cracking WPA With CPUs, GPUs, And The Cloud
By

WPA/WPA2, WinZip, WinRAR, Microsoft's native Data Encryption API, Apple's FileVault, TruCrypt, and OpenOffice all use PBKDF2 (Password-Based Key Derivation Function 2.0). The critical element here is that a password won’t directly grant access to whatever it's protecting. You need to generate a key (decryption code) from the password.

This is one of the most critical differentiators separating WEP and WPA. WEP doesn't obscure your password in an effective way. That is a huge security risk because hackers can directly extract it from packets sent during authentication. This makes it easy for those same folks to sit in parking lot or lounge around in a mall and break into networks. Once enough packets are gathered, extracting the key and connecting to the network is easy. WPA is different because the password is hidden in a code (in other words, it's hashed), forcing hackers to adopt a different tactic: brute-force cracking.

In one of our last security-oriented pieces, we noticed some confusion in the comments section where readers were asking for more clarification on concepts like rainbow tables, hashes, salting, and transformations.

There are two major parts to converting a password value to a decryption key. The first is called salting. It's possible you've heard this term used once or twice. This is a method in cryptography that prevents two systems from using the same key, even though they may share the same password. Without salting, a pair of machines using the same password, even coincidentally, end up with the same key. This is a vulnerability for rainbow tables, which are huge spreadsheets that allow you to look up the original password (provided you know the key). Salting largely nullifies the use of rainbow tables, because every password uses a random value to generate a different key. It also effectively renders password derivation a one-way function, because you can't backwards-generate passwords from keys. For example, SSIDs are used to salt WPA passwords. So, even if your neighbor uses the same password, he's going to have a different key if his router has a different name.

PBKDF2 takes things one step further by using a key derivation function (KDF). The idea itself is pretty simple, but it's a little math-heavy. There are two steps:

  1. Generate data1 & data2 from password and salt.
  2. Calculate key using transformation invocations using a loop, which looks like:

        for (int i=0; i<iteration_count; i++)
                {
                data1 = SHA1_Transform(data1, data2);
                data2 = SHA1_Transform(data2, data1);
                  }

Basically, you input the password and salt (the random bits) in order to generate the first data parameter. This represents the key in it's non-final form. From there, the key is continuously hashed in a cycle, where the next calculation relies on the previous one in order to continue. For every interval, the value of the key changes. Repeat this a couple thousand times and you have the final decryption key. And because you can't go backwards, brute-force cracking requires you to "recreate" the key on every password attempt.

This process accounts for 99% of the computational overhead required in brute-force cracking, so throwing copious compute muscle at that wall is really the only way to chisel it down. Hash cracking lets you to try multiple passwords at a time because the process doesn't employ a key derivation function or salt, making it magnitudes faster. As a practical matter, the impressive speeds you see from hash cracking shouldn't scare you. This form of brute-force hacking is limited in scope, since just about everything secure utilizes salting and a key derivation function.

To give you a sense of scale, WinZip uses 2002 SHA-1 transformation invocations to generate a key. This value is constant for any password length, up to 64 characters. That's why a 10-character password is just as easy to defeat with AES-256 as it is with AES-128. WPA, on the other hand, uses 16 388 transformations to convert a master key (MK) into what's known as a Pairwise Master Key (PMK). That makes brute-force cracking in WPA 8x slower than it does with WinZip/AES.

WPA relies on a Pre-Shared Key (PSK) scheme. You may enter in a master key (the value that you see in the password field on the router), but you can only "sniff out" the Pairwise Transient Key (PTK) during what is known as a "four-way handshake."

Authentication relies on deriving the PTK from a Pairwise Master Key, which is in turn derived from a master key. It takes about five or six more transformations to go from the PMK to PTK, but WPA cracking speeds are often presented in PMK units, the most computationally-intensive portion of the brute-force attack.
