Seasonic (Finally) Enters The Titanium Efficiency Club, Outs Several New PSUs


From now on, Seasonic's flagship line will be the Prime, which includes three families of products with Titanium, Platinum and Gold efficiency certifications. Seasonic was rather late to the Titanium efficiency club, but it's better to be late with a good product in hand. Without a doubt, Super Flower is pushing hard in the high-end category, and this means that Seasonic, along with the rest of the OEMs, has to carefully plan its next steps. However, we believe that competition is good for consumers because it pushes R&D teams to create better and less expensive products.


The Titanium Prime line consists of four members with 850W, 750W, 650W and 600W capacities. The smallest of them uses a passive design, meaning that it doesn't have a cooling fan, offering the lowest possible noise output. To the best of our knowledge, this the only Titanium fanless PSU available on the market. With 600W capacity, the fanless Prime unit will enable a super-silent build that also performs for gaming. The newest GPUs promise low energy consumption, meaning that you don't need a monstrous PSU to power two high-end graphics cards and a potent CPU--at stock speeds, at least.

The Platinum Prime line includes three members with 1.2 kW, 1 kW and 850W max power, and the Gold Primes feature exactly the same capacities. Finally, all Primes use a full-bridge topology along with an LLC resonant converter on the primary side.

Swipe to scroll horizontally
PowerPRIME Titanium: 850W, 750W, 650W, 600W (Fanless) PRIME Platinum: 1200W, 1000W, 850W PRIME Gold: 1200W, 1000W, 850W
PFCActive PFC
Efficiency80 Plus Titanium, Platinum, Gold
ModularYes (fully)
Intel Haswell ReadyYes
Operating temperature0°C ~ 50°C
ProtectionsOver Voltage Protection Under Voltage Protection Over Temperature Protection Short Circuit Protection Over Power Protection
Cooling135 mm Fluid Dynamic Bearing Fan (except the PRIME Titanium Fanless 600W)
Semi-passive operationYes (Selectable)
ComplianceATX12V v2.4, EPS 2.92
WarrantyPRIME Titanium: 10 years PRIME Platinum & Gold: 7 years

As you can see, Seasonic decided to offer up to 850W Titanium units; that decision might seem strange considering that Super Flower has a 1.6 kW Titanium unit in its portfolio.


Besides the high-end Prime models, Seasonic also revealed the Focus series, which is more price-focused according to the company. The Focus line includes three sub-lines that consist of fully modular, semi-modular and non-modular members. The Focus units utilize a half-bridge topology and an LLC resonant converter, on the primary side.

Swipe to scroll horizontally
PowerFocus Gold fully/semi/non-modular: 750W, 650W, 550W, 450W
PFCActive PFC
Efficiency80 Plus Gold
ModularSSR-xx0FX models: Yes (fully) SSR-xx0FM models: Yes (semi) SSR-xx0FC models: No xx = 45, 55, 65, 75
Intel Haswell ReadyYes
Operating temperature0°C ~ 50°C
ProtectionsOver Voltage Protection Under Voltage Protection Over Temperature Protection Short Circuit Protection Over Power Protection
Cooling120 mm Fluid Dynamic Bearing Fan
Semi-passive operationYes (Selectable)
ComplianceATX12V v2.4, EPS 2.92
Warranty5 years


Seasonic also introduced a Platinum Focus line, consisting of two sub-families with fully modular and semi-modular members. Their technical specifications and most important features are listed below.

Swipe to scroll horizontally
PowerFocus Platinum fully/semi: 750W, 650W, 550W, 450W
PFCActive PFC
Efficiency80 Plus Platinum
ModularSSR-xx0PX models: Yes (fully) SSR-xx0PM models: Yes (semi) xx = 45, 55, 65, 75
Intel Haswell ReadyYes
Operating temperature0°C ~ 50°C
ProtectionsOver Voltage Protection Under Voltage Protection Over Temperature Protection Short Circuit Protection Over Power Protection
Cooling120 mm Fluid Dynamic Bearing Fan
Semi-passive operationYes (Selectable)
ComplianceATX12V v2.4, EPS 2.92
Warranty5 years

The Focus lines include 20 members with Gold and Platinum efficiency certifications and all possible cable design configurations. This is hands down Seasonic's largest family of products.

Seasonic's new Air Touch unit features Platinum efficiency, a fully modular cabling design and 850W max power along with appealing external looks. This PSU also uses a 135mm Fluid Dynamic Bearing fan featuring a hybrid digital RGB fan control with a five-mode smart control interface. According to its manufacturer, the fan's speed and the RGB LED lights can be easily personalized through software. Only one touch of the user's finger is enough to set the desired fan speed and the ambient lighting color, which provides an indication about the fan's operational mode (red: turbo; yellow: high; green: mid; blue: low; white: silent). Finally, the Air Touch PSU is backed-up by a seven-year warranty.


The lower-end, budget friendly, Seasonic new PSU line is called ECO Plus. These units use a double-forward topology on the primary side and are 80 PLUS Bronze certified. The capacities of the ECO Plus models range from 400W to 600W, with all units featuring two PCIe connectors.

Swipe to scroll horizontally
PowerECO Plus: 400W, 500W, 600W
PFCActive PFC
Efficiency80 Plus Bronze
ModularNo
Intel Haswell ReadyYes
Operating temperature0°C ~ 50°C
ProtectionsOver Voltage Protection Under Voltage Protection Short Circuit Protection Over Power Protection
Cooling120 mm Fan
Dimensions (L x W x H)140mm x 150mm x 86mm
ComplianceATX12V v2.4, EPS 2.92
Warranty3 years
Aris Mpitziopoulos
Contributing Editor

Aris Mpitziopoulos is a contributing editor at Tom's Hardware, covering PSUs.

  • Lutfij
    A powerful line up nonetheless!
    Reply
  • Valantar
    "As you can see, Seasonic decided to offer up to 850W Titanium units; that decision might seem strange considering that Super Flower has a 1.6 kW Titanium unit in its portfolio."

    Only if you've bought into the ridiculous idea that only (increasingly rare) tri and quad GPU setups need or want high efficiency PSUs. Or, of course, the even dumber idea of buying ridiculously overpowered PSUs. That fanless 600W unit could probably run dual GTX 1080s in SLI with a <100W CPU, although it'd be getting close to max output when GPU power spikes (Tom's' own testing showed stock clocked 1080s averaging 173W under gaming loads, but spiking to ~300W). After all, what's the point of Titanium with its improved 10% load efficiency if that 10% is way beyond the idle power of your PC? Building a modern PC exceeding 1000W at non-power virus loads is really, really difficult.

    PC components are making huge strides in efficiency. It's time the PSU industry got it's foot out of its a** and keep up. Lian-li's new SFX-L PSUs seem like a good evolution - smaller PSUs with decent efficiency and low noise are a must for modern form factors. Proliferation of low output, high efficiency PSUs are a huge step in the right direction too.


    For me, the star of this line-up is the 450W Focus Platinum unit. From what I've seen, it's the first platinum efficiency unit offered at that low power - perfect for a high-end mainstream setup with a single GTX 1070 or 1080 (and probably Vega too), not to mention mainstream setups with R9 480s or GTX 1060s.
    Reply
  • Nuckles_56
    I really hoped to see a 450W titanium model but I guess I asked for too much
    Reply
  • Valantar
    18051736 said:
    I really hoped to see a 450W titanium model but I guess I asked for too much

    Yeah, would have loved to see that too. Seems we'll have to wait a while still, unfortunately. Although Platinum is still pretty good - when the alternative used to be Gold ...
    Reply
  • nycalex
    seasonic, please take my money!

    been using a x750 seasonic for 4 years, still going strong!
    Reply
  • bit_user
    18051736 said:
    I really hoped to see a 450W titanium model but I guess I asked for too much
    Yeah, would have loved to see that too.
    Yeah, I've been hoping/waiting for it.
    Reply
  • Samer1970
    Where are the ATX 1450 watts of length 140 mm Seasonic ? why are you lazy on short PSU ?

    it is possible to make !

    we have 600 watts SFX power supply of Dimensions : 120x63x100

    Thats 1260 mm^3 per watt

    ATX power is 150x86x140 , should give you 1433 WATTS 140 length !

    do it ! be smart , use dual chambers !!!

    Reply
  • Samer1970
    18051464 said:
    "As you can see, Seasonic decided to offer up to 850W Titanium units; that decision might seem strange considering that Super Flower has a 1.6 kW Titanium unit in its portfolio."

    Only if you've bought into the ridiculous idea that only (increasingly rare) tri and quad GPU setups need or want high efficiency PSUs. Or, of course, the even dumber idea of buying ridiculously overpowered PSUs. That fanless 600W unit could probably run dual GTX 1080s in SLI with a <100W CPU, although it'd be getting close to max output when GPU power spikes (Tom's' own testing showed stock clocked 1080s averaging 173W under gaming loads, but spiking to ~300W). After all, what's the point of Titanium with its improved 10% load efficiency if that 10% is way beyond the idle power of your PC? Building a modern PC exceeding 1000W at non-power virus loads is really, really difficult.

    PC components are making huge strides in efficiency. It's time the PSU industry got it's foot out of its a** and keep up. Lian-li's new SFX-L PSUs seem like a good evolution - smaller PSUs with decent efficiency and low noise are a must for modern form factors. Proliferation of low output, high efficiency PSUs are a huge step in the right direction too.


    For me, the star of this line-up is the 450W Focus Platinum unit. From what I've seen, it's the first platinum efficiency unit offered at that low power - perfect for a high-end mainstream setup with a single GTX 1070 or 1080 (and probably Vega too), not to mention mainstream setups with R9 480s or GTX 1060s.

    Actually server grade psu are very small and with high wattage ...

    we have Titanium 1600 watts PSU in 86x40x196 size , which means we can have upto 6000 watts in ATX of length 196 today !!! 150x86x196

    But they dont bring server grade technology to desktop sadly.

    Reply
  • turkey3_scratch
    18052405 said:
    Where are the ATX 1450 watts of length 140 mm Seasonic ?

    You're kidding me, right? If any manufacturer managed to cram a unit capable of 1450W in 140mm it'd probably suck=. A lot of stuff goes into PSU design, you know. If you even have hardware that will require even 1000W, no way in heckle-de-bob is your computer case going to be small and restricted to 140mm units. Sorry, but I'll stick to my units with very nice low ripple.

    Anyway, this is awesome! It seems the Focus units are going to take over the G Series. I'm looking forward to the Prime Series, too.
    Reply
  • Karlos101
    Anyone know if the Titanium and Platinum models are actually manufactured by Seasonic or if they are re-badge jobs?
    Reply
