SSD Performance In The Office: Nine Applications Benchmarked

By Andrew Ku
published

A number of metrics are used to quantify storage performance. If you're a regular Joe, you have to be wondering how such dry terminology can apply to office work. Rather than telling you, we're going to dissect several routine computing tasks.

WinRAR: Compressing

Swipe to scroll horizontally
Overall StatisticsWinRAR: Compressing
Elapsed Time00:18
Read Operations56
Write Operations177
Data Read1.51 MB
Data Written5.60 MB
Disk Busy Time0.03 s
Average Data Rate213.55 MB/s

When you compress data, you're essentially taking multiple files and assembling them into a single file that occupies less space. As a result, you might assume that this task would consist of sequential accesses. The opposite actually turns out to be true.

Why is this? All forms of data compression replace repeated occurrences of data with references to a single copy of that data existing earlier in the input (uncompressed) data stream.

Consequently, compression turns out to be mostly a random write-heavy operation. However, the amount of data the system reads and writes is greater than the sum of the uncompressed (~400 KB) and compressed files (1 MB).

I/O Trends:

  • 58% of all operations occur at a queue depth of one
  • 37% of all operations occur between a queue depth of two and eight
  • 11% of all data transferred is sequential
  • 12% of all operations are sequential
  • 29% of all operations are 4 KB in transfer size
  • 32% of all operations are 32 KB in transfer size
  • 14% of all operations are 128 KB in transfer size
  • 13% of all operations are 16 KB in transfer size

Andrew Ku
Topics
Storage
47 Comments Comment from the forums
  • amk-aka-Phantom
    Nice escape, Tom's... I was wondering "hmm, what kind of torrent will they download, 95% of them are copyright infringement"... nice :D And a good article, too - maybe now I can convince some of our "office-only-don't-need-fancy-hardware" clients to switch to SSDs, esp. considering the HDD price increases.
    Reply
  • iLLz
    I want an SSD so bad I can taste it. The biggest problem for me is Price and Size. For my system drive I would need at least 500-600 GB and these sized SSDs are way to much money. My Steam folder is like 280 GBs alone. I know alot of you are going to say just put Windows and the most critical apps on the SSD and the rest on my 1TB drive but that defeats the purpose in my book. I want all my apps to benefit from the SSD especially if I am going to invest so much money into it. Here's to hoping the prices come down and fast!
    Reply
  • mikewong
    Better question: which SSD is more affordable, and which is more... reliable?
    Reply
  • richboyliang
    SSD's are meant for holding only your operating system and a few key applications you can't live without. All your data/media should be stored on a regular, large hard disk.
    Reply
  • phamhlam
    Unless you are working with huge files like pictures and videos, there isn't much a need for a huge SSD. A pair or HDD in RAID combine with a SSD can give you even better capacity and speed. I think most consumers are better with a 90-120GB SSD and a nice large HDD. I got an alright 120GB SSD for $120 w/ rebate. A good 120GB SSD cost about $180-$220. Laptops can hold two drive if your replace your dvd drive which most people rarely use. Once you get a SSD, it is hard to go back.
    Reply
  • Proximon
    Your office is apparently far different that the ones I service :p At least you got a virus scan and MS Word typing in there.

    I suppose I can see some inexpensive reliable SSDs in office machines in the near future, mostly to reduce the failures connected with mechanical drives and speed up boot times and installation times.
    Reply
  • Zero_
    I dont get it :??:
    Reply
  • billybobser
    Office computer, files on server.

    SSD not really appropriate.

    Unless by office computer you mean where you have the only computer in the office, or files do not need to be shared around the office.

    Given the amount of work people do who open large files (where an ssd may be appropriate), they are too small/too expensive to be justified.

    Example, large 3d CaD drawings, spend extra money on them loading faster, lose funds for better overall computer (graphics especially).
    Reply
  • xtreme5
    still love ocz vertex3
    Reply
  • neiroatopelcc
    I've got a C300 in my work pc, and I have to say I'm disappointed. Not by the performance itself, but the overall result. Productivity went DOWN after the upgrade, as the size of the thing simply isn't adequate. You spend more time cleaning up and moving data than you do actually working. And I even had to move all my virtual machines to usb. That didn't exactly speed up anything either. Replacing a 750gb drive with a 120gb ssd simply isn't viable.

    I find it ironic that the only place your tiny ssd drives are good enough are in computers where speed isn't important in the first place. Until 320GB ssd's can compete with regular magnetic drives, it isn't an option to upgrade.

    Imagine the added cost of upgrading the 2442 registered clients to ssd drives! About half could make do with a 120GB drive, and the rest would need at least 160GB and possibly bigger.

    That's an expense you can't possibly gain in productivity.

    Replacing sas drives with ssd's might make sense for your database or vmware/hyper-v systems, but it isn't going to make much sense on the majority of workstations.
    Reply
