Back left to right, top to bottom: LAN port, optical audio jack, air vent, power in, DVI out, 2 USB 2.0 ports (stacked), S-Video out, line out (headphones), line out, microphone in, IEEE 1394 Firewire port, two more USB 2.0 ports (stacked)
Front left to right, top to bottom: power switch, CD/DVD drive slot, memory card reader (SD/MMC/MS/MS-pro), power light, USB 2.0 port, CD/DVD eject button
Front left to right, top to bottom : power switch, CD/DVD drive slot, memory card reader (SD/MMC/MS/MS-pro), power light, USB 2.0 port, CD/DVD eject button
Front and left side
Front and left side
Front and right side
Front and right side
Front and top
Front and top
The Shuttle XPC X100 operating vertically in its stand
The Shuttle XPC X100 operating vertically in its stand
AC power supply
AC power supply
