How We Test Power Supply Units

News
By
published

Our methodology, testing equipment, and benchmarks.

A PSU should be able to keep all of its rails within some predefined voltage ranges at all cases/loads. In Table 1, you will find these ranges (following the ATX v2.53 specification). With the introduction of ATX v3.0, there are some differences in load regulation since the new standard allows for higher voltage drops at +12V, up to 7% on all connectors but PCIe ones, where the voltage drop can go up to 8%.

DC Output Voltage Regulation

Swipe to scroll horizontally
Voltage NameRangeMinimumNominalMaximum
+12V1±5%11.40V12.00V12.60V
+12V2±5%11.40V12.00V12.60V
5V±5%4.75V5.00V5.25V
3.3V±5%3.14V3.30V3.47V
-12V±10%-10.80V-12.00V-13.20V
+5VSB±5%4.75V5.00V5.25V

Here's an example of a voltage regulation test results chart you'll find in each of our PSU reviews:
