Test Settings And Benchmarks

Swipe to scroll horizontally
Test Hardware Configurations
Row 0 - Cell 0 Customer Choice PCQ1 2012 SBM $1300 PC
Processor (Overclock)Intel Core i5-2500K 3.30 GHz, Four Physical CoresO/C to 4.53 GHz, 1.38 VIntel Core i5-2400 3.10 GHz, Four Physical CoresO/C to 3.69 GHz, 1.19 V
Graphics (Overclock)2 x EVGA GTX 560 Ti 1 GB: 850 MHz GPU,  GDDR5-4104O/C to 945 MHz GDDR5-4360PowerColor Radeon HD 7970: 975 MHz GPU, GDDR5-5500O/C to 1125 MHz GDDR5-6300
Memory (Overclock)8 GB G.Skill DDR3-1600 CAS 9-9-9-24, O/C at 1.60 V to DDR3-1612 CL 8-9-8-168 GB Corsair DDR3-1600 CAS 7-9-8-24, No DRAM O/C
Motherboard (Overclock)Intel DZ68BC LGA 1155, Intel Z68 ExpressO/C at 101 MHz BCLKASRock P67 Pro3 SE LGA 1155, Intel P67 ExpressNo BCLK O/C
OpticalAsus DRW-24B1ST: 24x DVD±RSamsung TS-H353C: 16x DVD-ROM
CaseAntec Nine HundredApevia X-Trooper Junior
CPU CoolerCooler Master Hyper 212 PlusCooler Master Hyper TX3
Hard DriveCrucial m4 128 GB, SATA 6Gb/s SSDCrucial m4 64 GB, SATA 6Gb/s SSD
PowerCorsair CMPSU-750HX: 750 W, 80 PLUS SilverCorsair CMPSU-650TXV2: 650 W, 80 PLUS Bronze
Software
OSMicrosoft Windows 7 Ultimate x64
GraphicsNvidia GeForce 296.10AMD Catalyst 12.2
ChipsetIntel INF 9.2.0.1030Intel INF 9.2.0.1030

From both a capabilities and cost perspective, the Newegg Customer Choice PC most closely resembles our own mid-range build with its $1300 budget. Although today's build is more expensive, that'll come out in our value comparison.

Swipe to scroll horizontally
Benchmark Configuration
3D Games
Battlefield 3Campaign Mode, "Going Hunting" 90-Seconds Fraps Test Set 1: Medium Quality Defaults (No AA, 4x AF) Test Set 2: Ultra Quality Defaults (4x AA, 16x AF)
DiRT 3V1.01, Run with -benchmark example_benchmark.xml Test Set 1: High Quality Preset, No AA Test Set 2: Ultra Quality Preset, 8x AA
Elder Scrolls V: SkyrimUpdate 1.4.27, Celedon Aethirborn Level 6, 25 Seconds Fraps Test Set 1: DX11, High Details No AA, 8x AF, FXAA enabled Test Set 2: DX11, Ultra Details, 8x AA, 16x AF, FXAA enabled
StarCraft IICustom map "Tom's Hardware Guide V2", 60 seconds Fraps Test Set 1: High Details, High Quality Test Set 2: Ultra Details, Extreme Quality
Audio/Video Encoding
iTunesVersion 10.4.1.10 x64: Audio CD (Terminator II SE), 53 minutes, default AAC format
Lame MP3Version 3.98.3: Audio CD "Terminator II SE", 53 min, convert WAV to MP3 audio format, Command: -b 160 --nores (160 kb/s)
HandBrake CLIVersion 0.95: "Big Buck Bunny" (720x480, 23.972 FPS) 5 Minutes, Audio: Dolby Digital, 48 000 Hz, Six-Channel, English, to Video: AVC Audio: AC3 Audio2: AAC (High Profile)
MainConcept ReferenceVersion: 2.2.0.5440: MPEG-2 to H.264, MainConcept H.264/AVC Codec, 28 sec HDTV 1920x1080 (MPEG-2), Audio: MPEG-2 (44.1 kHz, 2 Channel, 16-Bit, 224 Kb/s), Codec: H.264 Pro, Mode: PAL 50i (25 FPS), Profile: H.264 BD HDMV
Productivity
Adobe Photoshop CS5Version 12.1 x64: Filter 15.7 MB TIF Image: Radial Blur, Shape Blur, Median, Polar Coordinates
Autodesk 3ds Max 2012Version 12.0 x64: Space Flyby Mentalray, 248 Frames, 1440x1080
WinZipVersion 15.5 Pro: THG-Workload (650 MB) to ZIP, command line switches "-a -ez -p -r"
WinRARVersion 4.1: THG-Workload (650 MB) to RAR, command line switches "winrar a -r -m3"
7-ZipVersion 9.22: THG-Workload (650 MB) to .7z, command line switches "a -t7z -r -m0=LZMA2 -mx=5"
ABBYY FineReaderVersion 10.0.102.82: Read PDF save to Doc, Source: Political Economy (J. Broadhurst 1842) 111 Pages
Synthetic Benchmarks and Settings
3DMark 11Version: 1.0.1.0, Benchmark Only
PCMark 7Version: 1.0.4 x64, System, Productivity, Hard Disk Drive benchmarks
SiSoftware Sandra 2011Version 2011.10.17.80, CPU Test = CPU Arithmetic / MultiMedia, Memory Test = Bandwidth Benchmark
