Performance Rating
Our sample has a difference in performance from the previous generation Focus unit with similar capacity. Normally it should achieve the same performance, at least, but as it seems, our sample is not among the good ones of its production batch. The performance difference with the EVGA 650 G3 and the Corsair RM650x is notable, as you can see.
Noise Rating
The graph below depicts the cooling fan's average noise over the PSU's operating range, with an ambient temperature between 30 to 32 degrees Celsius (86 to 89.6 degrees Fahrenheit).
This is a silent power supply, but still far away from the Corsair RM650x.
Efficiency Rating
The following graph shows the PSU's average efficiency throughout its operating range with an ambient temperature close to 30 degrees Celsius.
The overall efficiency is satisfactory, although at light loads there is room for improvement.
MORE: Best Power Supplies
MORE: How We Test Power Supplies
MORE: All Power Supply Content
Current page: Performance, Noise and Efficiency
Prev Page Transient Response Tests, Timing Tests, Ripple Measurements and EMC Pre-Compliance Testing Next Page Bottom LineAris Mpitziopoulos is a contributing editor at Tom's Hardware, covering PSUs.
