AMD Athlon 64 vs. Intel Atom

Athlon Vs. Atom: Duel Of The Energy Savers

AMD and Intel both use 300 mm wafer disks in their production lines. At 77 mm², the Athlon 64 2000+ is more than three times larger than the Atom at 24 mm², which means Intel can produce and sell three times as many CPUs. in fact, Intel can get about 2,500 processors per wafer, while AMD can get only about 800.

Intel vs. AMD
CPU Atom Athlon 64
Power 4 Watts 8 Watts
Transistors 47 million 122 million
Size 24.18 mm² 77.2 mm²
Core Voltage 1.088 V 0.900 V

The Athlon 64 2000+ has 122 million transistors, and the Atom 230 only 47 million. If you look at the relationship between the number of transistors and energy consumption, a single Athlon 64 transistor uses less energy than an Atom transistor, even though Intel produces it using a 45 nm process while AMD relies on 65 nm manufacturing.

The Athlon 64 2000+ (OPN ADF2000IAV4DRE) runs on the Lima core at stepping G0. The HyperTransport frequency is 1000 MHz. This, of course, saves additional energy versus AMD’s more modern Phenom X3 and X4 CPUs. The Athlon 64 is on the same level as the Atom in terms of multimedia extensions, and the 64-bit instruction set has also been implemented.

Function Comparison Of The Intel And AMD CPU Series
Functions Pentium Dual-Core Celeron 220 Atom Z5 Series Atom N270 Atom 230 Athlon 64 2000+
Core Allendale Conroe-L Silverthorne Diamondville Diamondville Lima
Manufacturing 65 nm 65 nm 45 nm 45 nm 45 nm 65 nm
Socket 775 479 441 437 437 940
L1-Cache 32-KB Data 32-KB Instr. 32-KB Data 32-KB Instr. 32-KB Instr. 24-KB WB Data 32-KB Instr. 24-KB WB Data 32-KB Instr. 24-KB WB Data 64-KB Data 64-KB Instr.
L2-Cache 1MB 512 KB 512 KB 512 KB 512 KB 512 KB
FSB 200 MHz (800QDR) 133 MHz (533QDR) 100 MHz (400QDR) 133 MHz (533QDR) 133 MHZ (533QDR) 133 MHZ (533QDR) 200 MHz 1000HTT
64 Bit EM64T EM64T EM64T EM64T EM64T X86-64
HyperThreading - - Yes Yes Yes -
Virtualization VT - VT - - -
Energy Saving C1E Speedstep - C1E Speedstep C1E Speedstep - -
Thermal Monitor TM1&2 TM1&2 TM1&2 TM1&2 TM1&2 -
Virus Protection XD bit XD bit XD bit XD bit XD bit XD bit
