UPDATE: Core i7: Blazing Fast, O/C Changes

Page 3 of 37:

SSE 4.2 And The Technical Nitty-Gritty

SSE 4—Complete at Last

With the switch to its 45 nm production process, Intel introduced SSE4.1 into the Core 2 processors. As the ".1" implies, this was only the first iteration of the SSE4 instruction set, and was not yet fully complete. Now, Nehalem comes with the full complement of instructions enabled. Specifically, SSE4.2 adds seven new commands: CRC32, PCMPESTRI, PCMPESTRM, PCMPISTRI, PCMPISTRM, PCMPGTQ, and POPCNT.

The following table compares the technical specifications of the Core i7, Core 2 and AMD Phenom processor families.

Swipe to scroll horizontally

Feature	AMDPhenom	IntelCore i7	IntelCore 2
Core	AgenaToliman	Bloomfield	Yorkfield / XEWolfdaleKentsfield / XEConroe / XE / 2048Allendale
Production Process	65 nm	45 nm	65 nm45 nm
Max. Frequency	2.80 GHz	3.20 GHz	3.20 GHz
L1 Cache	64 + 64 KB	32 + 32 KB	32 + 32 KB
L2 Cache	512 KB	256 KB	4 MB
L3 Cache	2 MB	8 MB	-
Max. Thermal Loss (TDP)	140 W	130 W	136 W
CPU<->Northbridge	HyperTransport	QuickPath Interconnect	Front Side Bus
CPU<->CPU	HyperTransport	QuickPath Interconnect	Northbridge internal
Max. Core Speed	3.20 GHz (25.6 GB/s)	6.4 GT/s (12.8 GB/s)	400 MHz (12.8 GB/s)
Min. Core Speed	800 MHz (6.4 GB/s)	4.8 GT/s (9.0 GB/s)	200 MHz (6.4 GB/s)
FSB (internal)	200 MHz	133 MHz	400 MHz333 MHz266 MHz200 MHz
64-Bit	x86-64	EM64T	EM64T
Hyper-Threading	-	yes	-
MultimediaExtensions	MMX3DNow!SSESSE2SSE3SSE4.1	MMXSSESSE2SSE3SSSE3SSE4.1SSE4.2	MMXSSESSE2SSE3SSSE3SSE4.1
Virtualization	Pacifica	VT	VT
Power Saving	Cool‘n’Quiet 2	Enhanced Halt State (C1E)SpeedStep	Enhanced Halt State (C1E)SpeedStep
Thermal Protection	Thermal Diode	Thermal Monitor 2	Thermal Monitor 2
SpeedStep	no	yes	yes
Execution Protection	XD bit	XD bit	XD bit
TrustedExecution	Presidio	LaGrande Technology	LaGrande Technology
Active Management	no	iAMT2 (V-Pro)	iAMT2 (V-Pro)

Current page: SSE 4.2 And The Technical Nitty-Gritty
