Lian Li PC-Q30 Case Review: A Mini-ITX Chassis With Flair

Name: Lian Li PC-Q30 Technical Specifications And Features
Author: Igor Wallossek

by Igor Wallossek November 18, 2013 at 10:00 PM

Technical Specifications And Features

Lian Li's PC-Q30 employs horizontal airflow. Cool air enters through the two openings on either side of the case and is blown out the back, along with the system’s heat, via a fan. There’s no opening at the top, which means passive cooling isn't in the cards.

Technical Specifications
Model Number	PC-Q30
Form Factor	mini-ITX, DTX
Dimensions	223 mm (Width) x 357 mm (Height) x 300 mm (Depth)
Colors	Black or Silver (Outside and Inside are the Same)
Material	Aluminum
Weight	2.13 kg (Completely Empty) 2.30 kg (Empty)
5.25" (external)	None
3.5" (internal)	None
2.5" (internal)	4 x 2.5" for Hard Drive/SSD
Expansion Slots	2
Case Fans	1 x 140 mm
I/O Ports	2 x USB 3.0 / HD Audio
Component Size	Graphics Card: Up to 200 mm Length and 125 mm Height (Including Power Connectors) PSU: Up to 125 mm Length CPU Cooler: Up to 130 mm Height (Including Fan)
Power Supply	SFX (Not Included)
Street Price	Approximately $135

The power button on the front of the case features a blue LED to convey the system’s status and a red LED to show storage activity. It’s the same button used on many of Lian Li's other cases. There is no reset button.

The back of the enclosure's front cover exposes the attached cable, which you can detach. This actually makes installation easier, since the front cover can be set aside without detaching cables from the motherboard.

The front panel is more of a side. It sports two USB 3.0 and audio I/O (microphone input and headphone output).

The only potential issue we found was the PC-Q30’s four metal feet. They won't discolor the surface they're set on like the soft plastic ones tend to do, but they will scratch your desk if you're not careful. The lack of insulation against vibration didn't turn out to be a problem, surprisingly, due to the small footprint making contact.
