System Specifications
| ABS Ultimate 9 | |
|---|---|
| Chassis | Gigabyte 3D Aurora Aluminum |
| Power Supply | Enermax Liberty ELT620AWT 620 W |
| Processor(s) | Intel Core 2 Extreme
2.93 GHz @ 3.67 GHz, 1.066 GHz FSB, 4 MB L2 cache |
| Motherboard | Intel BOXD975XBXLKR (LGA 775) Intel 975X ATX |
| RAM | Corsair TwinX-2048-6400C4
4 x 1024 MB @ DDR666 (CL4.0-4-4-12) |
| Hard Drive | 2 x Western Digital Raptor, WD1500ADFD
150 GB, 10,000 rpm, 16 MB cache, SATA150 (in RAID 0) |
| Graphics Cards | ATI Radeon X1900XTX
640 MHz Core 775 MHz Memory (1.55 GHz DDR) ATI Radeon X1900XTX 625 MHz Core 725 MHz Memory (1.45 GHz DDR) |
| Sound Card | Onboard SigmaTel STAC9221 8 Channel Audio |
| Networking | 2 x On-Board Intel 82573 Gigabit Ethernet |
| Optical Drives | Sony 16x DVD-ROM
Samsung 18X DVD±R SH-S182M/BEBN |
| Floppy Drive | Mitsumi FA404 USB 2.0 Floppy Drive and 8-in-1 Card Reader |
| CPU Cooler | Gigabyte GH-WIU02 Galaxy II |
Test Setup
We used our reference system for performance comparison.
| System Hardware | |
|---|---|
| Processor(s) | AMD Athlon 64 FX-60
2.6 GHz, 1.0 GHz HT-Link, 1 MB L2 cache |
| Platform | Nvidia : Asus AN832-SLI Premium
NVIDIA nForce4 SLI, BIOS version 1205 Nvidia : Asus A8R32-MVP Premium ATI Xpress 3200 CrossFire, BIOS version 0404 |
| RAM | Corsair CMX1024-4400Pro
2x 1024 MB @ DDR400 (CL3.0-4-4-8) |
| Hard Drive | Western Digital Raptor, WD1500ADFD
150 GB, 10,000 rpm, 16 MB cache, SATA150 |
| Networking | On-Board nForce4 Gigabit Ethernet
Onboard Marvell Gigabit Ethernet |
| Graphics Cards | Powercolor Radeon X1900XTX 512 MB GDDR3
650 MHz Core 775 MHz Memory (1.55 GHz DDR) Nvidia Based Cards : XFX GeForce 7950GX2 1 GB GDDR3 570 MHz Core 775 MHz Memory (1.55 GHz DDR) Nvidia GeForce 7900GTX 512 MB GDDR3 675 MHz Core 820 MHz Memory (1.64 GHz DDR) |
| Power Supply | PC Power & Cooling Turbo-Cool 1,000W |
| System Software & Drivers | |
| OS | Microsoft Windows XP Professional 5.10.2600, Service Pack 2 |
| DirectX Version | 9.0c (4.09.0000.0904) |
| Graphics Driver(s) | ATI - Catalyst 6.9 WHQL
NVIDIA - Forceware 91.47 WHQL |
