Z390 on the Cheap: Overclocking a Core i5 With Three Budget Boards
Why you can trust Tom's Hardware
Conclusion
Bottom Line
We formulated this article to show the worth of less-expensive boards that failed to fully support the power load of Intel’s Core i9-9900K, but Gigabyte’s sample came later and surprised us by being the only $160 board not to fail. Sure its voltage regulator ran so hot with the i9-9900K under extended full load that we needed to choose between adding a fan or reducing our room temperature to prevent throttling, but even those methods wouldn’t fix the thermal issues of its two competitors. Yet it remains true that most buyers in the market for a cheap overclocking board will not use so expensive a processor, so we had to give the Z390 Extreme4 and MAG Z390 Tomahawk a retest under a more-realistic load. Yet while both boards passed our Core i5-9600K validation, neither worked particularly well under that compromise.
We were hoping for different winners for the features, overclocking, and performance aspects that would give us additional reasons to consider both the MAG Z390 Tomahawk and the Z390 Extreme4, but only one of those two achieved a single victory: The Z390 Extreme4’s combination of CPU PCIe bifurcation (for running multiple high-bandwidth devices), added controllers, and full RGB control gave it a single edge over the Z390 Gaming SLI’s sole feature of CPU PCIe bifurcation. The MAG Z390 Tomahawk didn’t even have that, though it did have a second network controller.
Rounding makes the performance difference between the ASRock Z390 Extreme4 and Gigabyte Z390 Gaming SLI appear as 4 percent. And just to put another nail in the coffin of an ASRock victory, the slightly-cheaper MAG Z390 Tomahawk outperformed it by nearly 3 percent.
Thus, even as we’d love to award the Z390 Extreme4’s extra features for added value, it simply didn’t perform competitively enough. And if we jump back to the efficiency chart, we can see that it really did produce terrible overall results.
Gigabyte already received Editor’s Choice praise in its review, but that decision was based primarily upon improved support of a CPU that most buyers in its price range won’t buy. Today’s test further justifies our earlier decision.
Row 0 - Cell 0 | Gigabyte Z390 Gaming SLI | ASRock Z390 Extreme4 | MSI MAG Z390 Tomahawk |
Features Winner | Row 1 - Cell 1 | ✓ | Row 1 - Cell 3 |
Overclocking Winner | ✓ | ✓ | ✓ |
Performance Winner | ✓ | Row 3 - Cell 2 | Row 3 - Cell 3 |
Overall Winner | ✓ | Row 4 - Cell 2 | Row 4 - Cell 3 |
MORE: Best Motherboards
MORE: How To Choose A Motherboard
MORE: All Motherboard Content
Stay On the Cutting Edge: Get the Tom's Hardware Newsletter
Get Tom's Hardware's best news and in-depth reviews, straight to your inbox.
-
g-unit1111 I'm not surprised at all that the Tomahawk lagged. I've always been impressed with Asrock's boards and I would definitely buy the Z390 Extreme if I were doing an Intel build.Reply -
Gurg I have an even less expensive ($119) MSI Z390 Gaming Plus with my overclocked 9600k (oc to 5.05 all cores) cooled by a Corsair H115i Pro paired with 1080ti. RAM is 16gb of Gskill 3600. The only issue I've had was that my second M.2 a Samsung 970 Evo used for storage runs a little bit slower than it should. My boot drive Hyper X M.2 runs at full speed. FireStrike Extreme 12708/Gr 13767/Ph 15954. Time Spy 9159/ Gr 9791/CPU 6707.Reply -
Crashman
I take other people's overclocking results with a grain of salt, because I rarely see anyone as strict about load testing as Tom's Hardware. Prime95 small FFTs is harsher than the loads most other sites use for this type of testing.Gurg said:I have an even less expensive ($119) MSI Z390 Gaming Plus with my overclocked 9600k (oc to 5.05 all cores) cooled by a Corsair H115i Pro paired with 1080ti. RAM is 16gb of Gskill 3600. The only issue I've had was that my second M.2 a Samsung 970 Evo used for storage runs a little bit slower than it should. My boot drive Hyper X M.2 runs at full speed. FireStrike Extreme 12708/Gr 13767/Ph 15954. Time Spy 9159/ Gr 9791/CPU 6707.
On the other hand, your response seems credible being that the difference isn't large, and that we didn't use the maximum voltage that the processor could have tolerated (thermally).
