World Of Warcraft: Cataclysm--Tom's Performance Guide

By Chris Angelini
published

Ready for the launch of Blizzard's World of Warcraft: Cataclysm expansion tomorrow? Is your PC? We test 24 different graphics cards from AMD and Nvidia, CPUs from AMD and Intel, and compare DirectX 9 to DirectX 11, showing you which settings to use.

AMD: Mainstream Cards At Good Quality

Once you duck below the Radeon HD 4870 mark, it becomes necessary to dial the visuals down a bit. The Radeon HD 4850 could probably handle High quality at 1680x1050 without a problem, but in order to simplify testing and generate meaningful numbers through 2560x1600, the following four cards are evaluated using the Good preset.

The 4850, 4770, and 4670 (with GDDR4 memory) are all capable enough at 1680x1050. Clearly the Radeon HD 4550's settings need a bit more massaging to make the card playable, though. That likely means less-demanding options to bring frame rates up.

Performance continues sliding as the game's resolution increases to 2560x1600. And yet, you'll still find the Radeon HD 4850 and 4770 largely playable. Meanwhile, the Radeon HD 4670 drops to the point where it's average frame rate is marginal.

Then again, few folks with 30" displays are likely running three-generation-old video cards and vice versa. So, let's look at 1920x1080 plotted out in one second samples.

For the most part, all three top cards deliver a reasonable experience in this metric.

Chris Angelini
Chris Angelini
Chris Angelini is an Editor Emeritus at Tom's Hardware US. He edits hardware reviews and covers high-profile CPU and GPU launches.
162 Comments Comment from the forums
  • Odem
    Kind of unfortunate to see if I had gone with an i5 750 instead of a 955 I'd be seeing more fps. Although the money I saved for the same frames in most other games leaves me happy.
    Reply
  • WOW only uses 2 cores by default. However youc an configure it to "quasi" use more cores. you have to manually edit your config.wtf and change the variable: SET processAffinityMask "3" (3 is the default meaning 2 cores) to the following values for respective processors:

    i7 Qudcore with Ht- 85
    Any Quadcore chips with no HT - 15
    i5 Quadcore which does not have HT as far as I know - 15
    i5 Dualcore with HT- 5
    Dualcore with HT- 5
    Dualcore without HT - 5
    AMD tricore - 7

    There used to be a blue post explaining the settings and how to calculate it for different cores. But the old forums got wiped.
    Reply
  • sudeshc
    not a that big fan of wow, but still happy to see that they do keep in mind that people also have low end hardware too.
    Reply
  • SpadeM
    I'm impressed, if Chris went to all that trouble to benchmark the new expansion for a mmorpg in such great detail it can me only 2 things:
    1. Chris is a closet WoW-player
    2. Really bored
    With that said, i really do hope to see more of these articles, albeit with a more demanding title on the bench, even if it's from a "lesser" developer/publisher combo.

    PS: I do hope ppl appreciate my sense of humor :P
    Reply
  • dirtmountain
    Damn fine job Mr. Angelini, the most comprehensive hardware guide i've ever seen for WoW. This will save me hours, if not days of time when talking to players about their systems. Much appreciated.
    Reply
  • Bluescreendeath
    The Intel CPU scaling part was lacking...i7 980X at 3.7GHz? For WoW? Really?

    And why only Corei CPUs? Where are all the Core2s? 75% of Intel users still use Core2s and 775s!
    Reply
  • voicu83
    i hate you so much tom's hardware ... now i have to go buy an intel proc instead of my phenom ii x4 :D ... and add a dx11 board on top of it ... oh well, there goes my santa's gift :P
    Reply
  • Moneyloo
    Simply astounded by the time and effort that must have went into this piece. It also makes me greatly look forward to my new Maingear desktop arriving on the 23rd just in time for Christmas. Dual OC gtx580s in sli with a corei7 FTW. Ultra everything here I come!
    Reply
  • cangelini
    SpadeMI'm impressed, if Chris went to all that trouble to benchmark the new expansion for a mmorpg in such great detail it can me only 2 things:1. Chris is a closet WoW-player2. Really boredWith that said, i really do hope to see more of these articles, albeit with a more demanding title on the bench, even if it's from a "lesser" developer/publisher combo. PS: I do hope ppl appreciate my sense of humor
    It's a little easier to talk about WoW since I've been playing it for way too long, but I definitely want to see us doing more comprehensive coverage of demanding titles on launch day. It's all a matter of trying to convince the software guys to give a hardware site early access to the game. That's the hard part :)
    Reply
  • mitch074
    With hardware-accelerated cursor now enabled, OpenGL has finally become usable in WoW; was there any testing done on that? Not only does it sometimes give a boost to Nvidia cards, it's also the 'default' setting for Linux players - incidentally, the ones who were asking for the feature for a while.
    Reply
