Why you can trust Tom's Hardware
To read about our monitor tests in-depth, please check out Display Testing Explained: How We Test PC Monitors. We cover brightness and contrast testing on page two.
Uncalibrated – Maximum Backlight Level
All the displays here are based on the same LG part. So why do their SDR brightness values differ? Because each has a different implementation of variable brightness. All OLEDs use this technique to save energy and to avoid over-driving the panel. Some have a constant brightness option but the PX277 OLED MAX does not. It varies brightness, not too aggressively, but just enough to enhance perceptual contrast. With an SDR peak of 475 nits, plenty of light is available. Black levels can’t be measured, so neither can the contrast.
After Calibration to 200 nits
Calibration does not affect contrast. For testing purposes, I set a 25% window to 200 nits. When I got to the hands-on part of the review, I upped the brightness slider a bit. All OLEDs react differently to the brightness control, so you’ll have to set your PX277 OLED MAX to taste. Black levels remain unmeasurable from a checkerboard pattern, so intra-image contrast cannot be determined.
Test Takeaway: The PX277 OLED MAX has the same infinite blacks and contrast as any other OLED monitor. It has a higher SDR peak than most, which is more than one would need for an indoor environment. Its variable brightness feature is non-aggressive, so you might need to set brightness a bit higher for this monitor to get the picture you want.
MORE: Best Gaming Monitors
MORE: How We Test PC Monitors
MORE: How to Buy a PC Monitor
Current page: Brightness and Contrast
