Intel's Bean Canyon NUCs Hit the Shelves

At the beginning of July, we got word that Intel was readying its Bean Canyon NUC (Next Unit of Computing) for an eminent launch. Later that month the chipmaker later released a document detailing its technical specifications. After much anticipation, the Bean Canyon NUCs have finally come out of the oven and are available for purchase.

Intel's Bean Canyon NUCs come equipped with Intel's 8th generation Coffee Lake-U 28W processors, which feature Intel Iris Plus Graphics 655 and 128MB of eDRAM. They are sold as barebone kits without memory, storage, or an operating system.

The base model features an Intel Core i3-8109U dual-core processor with hyper-threading technology and has a $299 price tag.

Latest Videos FromTom's Hardware

The intermediate model carries an Intel Core i5-8259U quad-core chip with hyper-threading and costs $399.

Both the Core i3 and Core i5 models come in two variants. They are available with and without an optional 2.5-inch SATA bay for adding a SSD or HDD.

Finally, the top-end NUC employs an Intel Core i7-8559U quad-core processor with hyper-threading and will set you back $499.

All four Bean Canyon NUCs are available for purchase at Intel's website.

Swipe to scroll horizontally
Model NUC8i3BEK NUC8i3BEH NUC8i5BEK NUC8i5BEH NUC8i7BEH
Processor Intel Core i3-8109U Intel Core i3-8109U Intel Core i5-8259U Intel Core i5-8259U Intel Core i7-8559U
Cores / Threads 2 / 4 2 / 4 4 / 8 4 / 8 4 / 8
Base Clock / Turbo Clock 3GHz / 3.6GHz 3GHz / 3.6GHz 2.3GHz / 3.8GHz 2.3GHz / 3.8GHz 2.7GHz / 4.5GHz
Graphics Iris Plus Graphics 655 Iris Plus Graphics 655 Iris Plus Graphics 655 Iris Plus Graphics 655 Iris Plus Graphics 655
DDR4 SO-DIMM Slots 2 2 2 2 2
Max Memory 32GB 32GB 32GB 32GB 32GB
Storage 1x M.2 PCIe 3.0 x4 slot 1x M.2 PCIe 3.0 x4 slot1x 2.5 inches 9.5mm SATA III bay 1x M.2 PCIe 3.0 x4 slot 1x M.2 PCIe 3.0 x4 slot1x 2.5 inches 9.5mm SATA III bay 1x M.2 PCIe 3.0 x4 slot1x 2.5 inches 9.5mm SATA III bay
Removable Memory Card Slot microSDXC with UHS-I support microSDXC with UHS-I support microSDXC with UHS-I support microSDXC with UHS-I support microSDXC with UHS-I support
USB Ports 2x front USB 3.1 Gen 22x rear USB 3.1 Gen 21x Thunderbolt 3 2x front USB 3.1 Gen 22x rear USB 3.1 Gen 21x Thunderbolt 3 2x front USB 3.1 Gen 22x rear USB 3.1 Gen 21x Thunderbolt 3 2x front USB 3.1 Gen 22x rear USB 3.1 Gen 21x Thunderbolt 3 2x front USB 3.1 Gen 22x rear USB 3.1 Gen 21x Thunderbolt 3
Graphics Output 1x HDMI 2.0a1x USB-C (DisplayPort 1.2) 1x HDMI 2.0a1x USB-C (DisplayPort 1.2) 1x HDMI 2.0a1x USB-C (DisplayPort 1.2) 1x HDMI 2.0a1x USB-C (DisplayPort 1.2) 1x HDMI 2.0a1x USB-C (DisplayPort 1.2)
Internet Connectivity IntelWireless-AC 9560 802.11ac 2x2 + Bluetooth v510/100/1000 Mbps Ethernet IntelWireless-AC 9560 802.11ac 2x2 + Bluetooth v510/100/1000 Mbps Ethernet IntelWireless-AC 9560 802.11ac 2x2 + Bluetooth v510/100/1000 Mbps Ethernet IntelWireless-AC 9560 802.11ac 2x2 + Bluetooth v510/100/1000 Mbps Ethernet IntelWireless-AC 9560 802.11ac 2x2 + Bluetooth v510/100/1000 Mbps Ethernet
Pricing $299 $299 $399 $399 $499
