To learn more about our PSU tests and methodology, please check out How We Test Power Supply Units.
Primary Rails And 5VSB Load Regulation
The following charts show the main rails' voltage values recorded between a range of 40W up to the PSU's maximum specified load, along with the deviation (in percent). Tight regulation is an important consideration every time we review a power supply, because it facilitates constant voltage levels despite varying loads. Tight load regulation also, among other factors, improves the system's stability, especially under overclocked conditions. At the same time, it applies less stress to the DC-DC converters that many system components utilize.
Load regulation is loose on all rails.
Hold-Up Time
Simply put; hold-up time is the amount of time that the system can continue to run without shutting down or rebooting during a power interruption.
The hold-up time is a bit lower than 17ms, and the power ok signal doesn't reach 16ms.
Inrush Current
Inrush current, or switch-on surge, refers to the maximum, instantaneous input current drawn by an electrical device when it is first turned on. A large enough inrush current can cause circuit breakers and fuses to trip. It can also damage switches, relays, and bridge rectifiers. As a result, the lower the inrush current of a PSU right as it is turned on, the better.
Inrush current is at normal levels with 115V and on the high side with 230V.
Leakage Current
In layman's terms, leakage current is the unwanted energy transfer from one circuit to another. In power supplies, it is the current flowing from the primary side to the ground or the chassis, which in most cases is connected to the ground. We use a GW Instek GPT-9904 electrical safety tester instrument to measure leakage current.
The leakage current test is conducted at 110% of the DUT's rated voltage input (so for a 230-240V device, we should conduct the test with 253-264V input). The maximum acceptable limit of a leakage current is 3.5 mA. The IEC-60950-1 regulation defines it as ensuring that the current is low and will not harm any person coming in contact with the power supply's chassis.
Leakage current is dead low.
10-110% Load Tests
These tests reveal the PSU's load regulation and efficiency levels under high ambient temperatures. They also show how the fan speed profile behaves under increased operating temperatures.
Test # | 12V | 5V | 3.3V | 5VSB | DC/AC (Watts) | Efficiency | Fan Speed (RPM) | PSU Noise (dB[A]) | Temps (In/Out) | PF/AC Volts |
1 | 2.749A | 1.979A | 1.983A | 0.997A | 54.954 | 83.695% | 612 | 10.7 | 40.39°C | 0.976 |
Row 2 - Cell 0 | 12.132V | 5.053V | 3.329V | 5.016V | 65.660 | Row 2 - Cell 6 | Row 2 - Cell 7 | Row 2 - Cell 8 | 45.53°C | 115.15V |
2 | 6.535A | 2.978A | 2.981A | 1.199A | 110.012 | 88.042% | 632 | 11.9 | 40.59°C | 0.976 |
Row 4 - Cell 0 | 12.106V | 5.038V | 3.320V | 5.003V | 124.954 | Row 4 - Cell 6 | Row 4 - Cell 7 | Row 4 - Cell 8 | 46.49°C | 115.15V |
3 | 10.670A | 3.482A | 3.488A | 1.403A | 165.003 | 89.304% | 674 | 16.0 | 41.53°C | 0.979 |
Row 6 - Cell 0 | 12.085V | 5.027V | 3.312V | 4.990V | 184.765 | Row 6 - Cell 6 | Row 6 - Cell 7 | Row 6 - Cell 8 | 47.88°C | 115.15V |
4 | 14.821A | 3.988A | 3.993A | 1.607A | 220.001 | 89.561% | 733 | 17.0 | 41.68°C | 0.985 |
Row 8 - Cell 0 | 12.064V | 5.016V | 3.305V | 4.978V | 245.644 | Row 8 - Cell 6 | Row 8 - Cell 7 | Row 8 - Cell 8 | 48.64°C | 115.15V |
5 | 18.643A | 5.001A | 5.008A | 1.813A | 274.989 | 89.270% | 810 | 22.2 | 42.25°C | 0.989 |
Row 10 - Cell 0 | 12.041V | 5.000V | 3.296V | 4.963V | 308.043 | Row 10 - Cell 6 | Row 10 - Cell 7 | Row 10 - Cell 8 | 50.44°C | 115.15V |
6 | 22.480A | 6.021A | 6.026A | 2.000A | 329.879 | 88.670% | 921 | 25.7 | 43.06°C | 0.989 |
Row 12 - Cell 0 | 12.018V | 4.984V | 3.287V | 4.949V | 372.030 | Row 12 - Cell 6 | Row 12 - Cell 7 | Row 12 - Cell 8 | 52.24°C | 115.15V |
7 | 26.346A | 7.048A | 7.051A | 2.229A | 385.052 | 87.836% | 1045 | 30.8 | 43.55°C | 0.989 |
Row 14 - Cell 0 | 11.992V | 4.967V | 3.277V | 4.934V | 438.378 | Row 14 - Cell 6 | Row 14 - Cell 7 | Row 14 - Cell 8 | 53.65°C | 115.15V |
8 | 30.211A | 8.003A | 8.081A | 2.439A | 439.550 | 86.802% | 1217 | 36.2 | 43.72°C | 0.990 |
Row 16 - Cell 0 | 11.967V | 4.950V | 3.267V | 4.920V | 506.382 | Row 16 - Cell 6 | Row 16 - Cell 7 | Row 16 - Cell 8 | 54.85°C | 115.14V |
9 | 34.497A | 8.608A | 8.589A | 2.443A | 494.460 | 85.775% | 1413 | 39.5 | 44.58°C | 0.991 |
Row 18 - Cell 0 | 11.942V | 4.937V | 3.260V | 4.912V | 576.461 | Row 18 - Cell 6 | Row 18 - Cell 7 | Row 18 - Cell 8 | 56.34°C | 115.14V |
10 | 38.603A | 9.137A | 9.133A | 3.069A | 549.683 | 84.415% | 1667 | 43.9 | 45.88°C | 0.992 |
Row 20 - Cell 0 | 11.916V | 4.925V | 3.251V | 4.887V | 651.170 | Row 20 - Cell 6 | Row 20 - Cell 7 | Row 20 - Cell 8 | 58.08°C | 115.15V |
11 | 43.332A | 9.150A | 9.150A | 3.073A | 604.871 | 83.177% | 1896 | 46.8 | 46.62°C | 0.993 |
Row 22 - Cell 0 | 11.889V | 4.919V | 3.245V | 4.880V | 727.213 | Row 22 - Cell 6 | Row 22 - Cell 7 | Row 22 - Cell 8 | 59.28°C | 115.14V |
CL1 | 0.100A | 14.001A | 13.999A | 0.000A | 116.082 | 83.017% | 1027 | 29.9 | 42.34°C | 0.973 |
Row 24 - Cell 0 | 12.114V | 4.923V | 3.282V | 4.999V | 139.829 | Row 24 - Cell 6 | Row 24 - Cell 7 | Row 24 - Cell 8 | 50.02°C | 115.17V |
CL2 | 45.830A | 1.000A | 1.001A | 1.000A | 558.730 | 84.924% | 1680 | 44.6 | 45.15°C | 0.992 |
Row 26 - Cell 0 | 11.902V | 5.011V | 3.281V | 4.965V | 657.918 | Row 26 - Cell 6 | Row 26 - Cell 7 | Row 26 - Cell 8 | 58.61°C | 115.14V |
There are no problems under high temperatures and full load conditions. You should not apply such harsh conditions for prolonged periods if you want to keep the PSU alive for long.
20-80W Load Tests
In the following tests, we measure the PSU's efficiency at loads significantly lower than 10% of its maximum capacity (the lowest load the 80 PLUS standard measures). This is important for representing when a PC is idle with power-saving features turned on.
Test # | 12V | 5V | 3.3V | 5VSB | DC/AC (Watts) | Efficiency | Fan Speed (RPM) | PSU Noise (dB[A]) | PF/AC Volts |
1 | 1.221A | 0.494A | 0.494A | 0.198A | 19.982 | 72.501% | 546 | 6.5 | 0.927 |
Row 2 - Cell 0 | 12.146V | 5.071V | 3.337V | 5.044V | 27.561 | Row 2 - Cell 6 | Row 2 - Cell 7 | Row 2 - Cell 8 | 115.15V |
2 | 2.445A | 0.987A | 0.990A | 0.397A | 39.972 | 81.829% | 567 | 8.0 | 0.968 |
Row 4 - Cell 0 | 12.137V | 5.064V | 3.334V | 5.036V | 48.848 | Row 4 - Cell 6 | Row 4 - Cell 7 | Row 4 - Cell 8 | 115.15V |
3 | 3.674A | 1.482A | 1.486A | 0.597A | 60.003 | 85.157% | 588 | 8.9 | 0.980 |
Row 6 - Cell 0 | 12.128V | 5.058V | 3.330V | 5.027V | 70.462 | Row 6 - Cell 6 | Row 6 - Cell 7 | Row 6 - Cell 8 | 115.15V |
4 | 4.898A | 1.980A | 1.986A | 0.797A | 79.955 | 86.854% | 610 | 10.4 | 0.981 |
Row 8 - Cell 0 | 12.117V | 5.051V | 3.326V | 5.019V | 92.057 | Row 8 - Cell 6 | Row 8 - Cell 7 | Row 8 - Cell 8 | 115.15V |
The fan spins at low speed with light loads, boosting efficiency by keeping its energy consumption low.
2% or 10W Load Test
From July 2020, the ATX spec requires 70% and higher efficiency with 115V input. The applied load is only 10W for PSUs with 500W and lower capacities, while for stronger units, we dial 2% of their max-rated capacity.
Test # | 12V | 5V | 3.3V | 5VSB | DC/AC (Watts) | Efficiency | Fan Speed (RPM) | PSU Noise (dB[A]) | PF/AC Volts |
1 | 0.735A | 0.232A | 0.232A | 0.048A | 11.120 | 61.692% | 419 | <6.0 | 0.866 |
Row 2 - Cell 0 | 12.144V | 5.072V | 3.337V | 5.048V | 18.025 | Row 2 - Cell 6 | Row 2 - Cell 7 | Row 2 - Cell 8 | 115.15V |
The 60% mark is passed, but the 70% mark is far away.
Efficiency & Power Factor
Next, we plotted a chart showing the PSU's efficiency at low loads and loads from 10 to 110% of its maximum rated capacity. The higher a PSU’s efficiency, the less energy goes wasted, leading to a reduced carbon footprint and lower electricity bills. The same goes for Power Factor.
Efficiency with normal loads is high, achieving top place compared to other Bronze-rated (in the 80 PLUS scheme) units. On the other hand, with a 2% load, the CX550F doesn't do so well.
5VSB Efficiency
Test # | 5VSB | DC/AC (Watts) | Efficiency | PF/AC Volts |
1 | 0.100A | 0.504 | 74.118% | 0.108 |
5.046V | 0.680 | 115.15V | ||
2 | 0.250A | 1.260 | 77.970% | 0.212 |
5.042V | 1.616 | 115.15V | ||
3 | 0.550A | 2.768 | 79.267% | 0.314 |
5.034V | 3.492 | 115.15V | ||
4 | 1.000A | 5.022 | 79.917% | 0.376 |
5.022V | 6.284 | 115.16V | ||
5 | 1.500A | 7.514 | 79.530% | 0.410 |
5.010V | 9.448 | 115.16V | ||
6 | 2.999A | 14.912 | 77.116% | 0.456 |
4.972V | 19.337 | 115.16V |
The 5VSB rail has higher efficiency than the average. There is still room for improvement, though.
Power Consumption In Idle And Standby
Mode | 12V | 5V | 3.3V | 5VSB | Watts | PF/AC Volts |
Idle | 12.150V | 5.072V | 3.337V | 5.051V | 6.014 | 0.535 |
Row 2 - Cell 0 | Row 2 - Cell 1 | Row 2 - Cell 2 | Row 2 - Cell 3 | Row 2 - Cell 4 | Row 2 - Cell 5 | 115.2V |
Standby | Row 3 - Cell 1 | Row 3 - Cell 2 | Row 3 - Cell 3 | Row 3 - Cell 4 | 0.055 | 0.009 |
Row 4 - Cell 0 | Row 4 - Cell 1 | Row 4 - Cell 2 | Row 4 - Cell 3 | Row 4 - Cell 4 | Row 4 - Cell 5 | 115.2V |
Vampire power is low.
Fan RPM, Delta Temperature, And Output Noise
All results are obtained between an ambient temperature of 37 to 47 degrees Celsius (98.6 to 116.6 degrees Fahrenheit).
Under harsh conditions, the fan speed profile is not aggressive since the fan's RPMs increase linearly.
The following results were obtained at 30 to 32 degrees Celsius (86 to 89.6 degrees Fahrenheit) ambient temperature.
At normal operating temperatures, close to 30 degrees Celsius, the PSU is silent with loads up to 300W. The 30dBA mark is passed with 350W and higher loads, while the PSU enters the 35-40dBA zone with 400W.
