System Builder Marathon, December 2008: The Articles
Here are links to each of the four articles in this month’s System Builder Marathon (we’ll update them as each story is published).
- Day 1: The $650 Gaming PC
- Day 2: The $1,250 Mid-Range PC
- Day 3: The $2,500 Enthusiast PC
- Day 4: Performance and Value Dissected
Ed.—You’ll notice that we have once again paired up with NewEgg to deliver this month’s SBM. It’s an arrangement that gives us access to the latest retail components, which ideally delivers an experience more representative of what our readers would go through and eliminates the uncertainty associated with engineering/cherry-picked samples. Good news--you'll notice that this month we're back to three distinct system builds. That's because i7 is now widely available and we were able to build it into our high-end. There's also a bit of a surprise on day two. But for now, check out what Paul was able to piece together for $625!
Introduction
Readers seemed to appreciate the November SBM pricing points so we again stick to the $625 budget for this month’s Gaming PC. Many of our previous components also found their way into this system, but there was a little extra room in the budget to allow for a potential upgrade or two.
Our maximum-detail SBM gaming settings have so far brought our single-GPU gaming PCs to their knees, so attempts were first made to fit more GPU power into this month’s build. Ideally, dual HD 4830s or 9800 GTs were the goal, but unfortunately a CrossFire- or SLI-capable motherboard, dual $115 graphics cards, and a sufficient power supply unit (PSU) did not even come close to meeting the constraints of this budget. Even a single GTX 260 or HD 4870 would have required the HDD capacity or system memory to be cut in half and would have also limited us to $30 cases. While more GPU power remained just out of reach, there were enough pricing changes to instead increase our CPU budget so we could take a look at the Intel Core 2 Duo E7300.
With slightly higher stock clock speeds, a higher front side bus (FSB) clock, and more L2 cache, we expected the E7300-powered system to outperform November's E5200 setup right out of the box. But since this is an SBM review, we are thus more interested in seeing just what this rig will do once we find its maximum stable overclocked speeds. Let’s take a look at the other components selected for this month’s $625 Gaming PC.
| $625 Gaming PC System Components | ||
|---|---|---|
| Component | Model | Price (USD) |
| CPU | Intel Core 2 Duo E7300 2.66 GHz | 120 |
| CPU Cooler | Arctic Cooling Freezer 7 Pro | 27 |
| Motherboard | Gigabyte GA-EP45-DS3L | 105 |
| RAM | Patriot Viper 4 GB (2 x 2 GB) DDR2 800 (PC2 6400) | 53 |
| Graphics | Sapphire 100245L Radeon HD 4850 512 MB | 150 |
| Hard Drives | Seagate Barracuda 7200.11 ST3500320AS 500 GB 7200 RPM 32 MB | 65 |
| Sound | Integrated HD Audio | 0 |
| Network | Integrated Gigabit Networking | 0 |
| Case | Antec Three Hundred | 50 |
| Power | Antec NeoPower 430 430 W ATX12V | 40 |
| Optical | LITE-ON 20X DVD±R SATA Model iHAS120-04 | 22 |
| Total Price: | $632 | |
A few pricing changes on order day brought the $624 in selected components up to a slightly over-budget $632. The one change most worth mentioning is that the $10 savings on the E7300 expired, meaning we needed to obtain an extra $38 worth of performance out of this CPU vs. last month's E5200. And while we are on the topic, once again keep in mind that these prices and even availability are almost guaranteed to change by the time you read this article. Also, some readers may value knowing there were $40 worth of mail-in rebates available for these components at order time. With that said, it’s time to take a closer look at each of the components used in the December $625 PC.
- More CPU, Please
- CPU And Cooler
- Motherboard And Memory
- Graphics Card And Hard Drive
- Case, Power Supply, And Optical Drive
- Assembly And Overclocking
- Test System And Benchmarks
- Benchmark Results: Crysis And Unreal Tournament 3
- Benchmark Results: World In Conflict And Supreme Commander
- Benchmark Results: Audio/Video Encoding
- Benchmark Results: Applications
- Benchmark Results: Synthetics
- Power Consumption
- Conclusion
Its always about value at the price points.
regarding nvidia ion, i think intel is thinking deeply of whether they allow nvidia to Atom since netbooks still sell without it.
Intel Quad Core Q6600
Asus P5QL Pro Motherboard
NVidia 9800 GTX
GSkill 4 Gb Ram
580 Watt PSU
Rosewill Mid-Tower
160 GB 7200 RPM Hard Drive
SATA CD/DVD Burner
$82 2.5GHz E5200 45nm C2D
$0 (no CPU cooler)
$54 ASUS P5KPL-CM
$34 A-DATA 2x2GB (4GB) DDR2 800
$200 GeForce 260
$55 WD 320GB WD3200AAKS
$0 integrated sound
$0 integrated network
$12 Spray painted an old beige case black.
$67 500W SeaSonic
$22 LG DVD burner
$10 card reader
$526 Total
I don't see why they didn't shave off $40 for the cheaper CPU
Prices are good till tommorrow evening (tuesday) at 9 o clock when the store closes. Things are in bold are better deals than listed above.
Intel Core 2 Duo Processor E7300 & ECS GF7050VT-M Motherboard $99.99
Patriot 4GB DDR2 PC6400 Dual Memory $49.99 with a 20 dollar rebate
Antec Three Hundred Ultimate Gamer Case $34.99
Antec Earthwatts 500W Power Supply $49.99
Seagate 1.5TB Serial ATA/300 Hard Drive $129.99
Also good deals
crucial 4GB DDR2 PC8500 Dual Memory $47.99 $35.99 after rebate
crucial 2GB DDR2 PC6400 Dual Memory $19.99
I am just mad that I didn't get the e8500 + crappy motherboard for 134.99 that they had last week.
note for 99 dollars this is the e7300 not the e7200 the new chip with the higher multipler and is more likely to be a higher bin sort.
dual core which are practically core2duo's with less cache.
Their is no practically about it, Pentium Dual Cores (unlike Pentium Ds also known as netburst) are the same architecture as Intel Core 2 Duos. They are even made on the same wafer as the high end e8600s. Only difference is not all their cache worked perfectly and/or they didn't go as high as frequencies so they were binsorted into dual cores. Finally intel deactivated the cache that may have worked fine/or may not have worked fine and set the multipler to 12.5 and the bus speed at 200mhz.
$82 2.5GHz E5200 45nm C2D ...
...
I don't see why they didn't shave off $40 for the cheaper CPU
because that's the cpu they used last month and they wanted to try something different this time, something more powerful.
as they said in the article, it didn't work out the way they hoped and they won't be using it again
Lastly, I think the rig can still be overclocked further while keeping the same voltages - if only TH had time to play with the clock skews.
http://www.anandtech.com/guides/showdoc.aspx?i=3486
You could give the 7300 another shake next month to check if you just had an unlucky CPU, or the 5200 to see if it was just lucky etc. I just built a 5200 + GA-EP43-DS3L for a friend that went to 3.6 on stock cooling and 1.3625v easily.
No one is telling you to go AMD for $625 so why should you? The best bang for the buck at $625 is an Intel system.
BTW, a quad core is needed to play GTA4.
Operating System: Windows XP SP2
Processor: Dual core processor (Intel Pentium D or better)
RAM: 2GB
Hard Drive: 18GB free hard disk space
Video Card: 512MB Direct3D 10 compatible video card or Direct3D 9 card compatible with Shader
Drive: DVD-ROM dual-layer drive
I have the game and it is very CPU bounded. The recommended spec is a joke as a system with P4D + 8600GT simply couldn’t play the game.
