BIOS And Overclocking
The Fatal1ty FP-IN9 SLI supports an extreme range of CPU core voltage levels far beyond anything needed to reach a processor's maximum potential. The DRAM selections are a little more conservative but still high enough to reach beyond the stability limits of most memory. The FSB frequency selection also goes well beyond chipset capabilities. Exceeding the need is never a bad thing, so long as owners overclock responsibly.
|BIOS Frequency and Voltage settings (for overclocking)|
|FSB Frequency||100 - 750 MHz (1 MHz)|
|Clock Multiplier Adjustment||Yes|
|DRAM Frequency||400-1400 MHz Data Rate|
|PCIe Clock||100-200 MHz (1 MHz)|
|CPU Vcore||1.325 - 1.70000 Volts (0.025 Volts)|
|CPU FSB Voltage||1.20 - 1.65 Volts (~0.04V)|
|Northbridge (SPP)||1.20 - 1.58 Volts (~0.04V)|
|DRAM Voltage||1.80 - 2.10 - 2.50 Volts (0.05/0.10 Volts)|
|CAS Latency Range|
|tCAS: 1-6; tRCD: 1-15; tRP: 1-15; tRAS: 1-31; Command Rate: 1T/2T|
The Fatal1ty FP-IN9 SLI was completely stable at this processor's previously-discovered 3460 MHz limit at 1.50V, and went further to an acceptable 408 MHz bus (FSB1616) by dropping its multiplier to 6x. Remembering that our pre-retail E6700 doesn't have the same FSB capabilities of modern samples, we were still hoping to reach at least 450 MHz bus clock.
|Documentation & Software||Motherboard ManualFatal1ty Promo CardJumper Settings CardMotherboard Driver CD|
|Hardware||1x 80-conductor Ultra ATA cable1x Floppy Drive Cable4x SATA Data Cable1x I/O Panel Shield1x SLI Bridge1x SLI Bridge Clamp|
The Fatal1ty FP-IN9 SLI includes nearly every internal cable the builder might use, except for a second ATA133 cable. Abit even includes a floppy cable, though the board's floppy connector position means the company obviously doesn't expect you to use it.
With no support for serial or parallel ports the lack of any breakout cables isn't surprising. The front panel bays of most cases are adequate for using up the front panel audio and two internal USB connections.
Prices for the Abit Fatal1ty FP-IN9 SLI start at around $130.
