Mini-ITX CPU Air Cooler Round-Up

Name: Mini-ITX CPU Air Cooler Round-Up
Author: Chris Miconi

by Chris Miconi January 15, 2016 at 12:00 PM

Today we're reviewing the SilverStone Argon AR06, Reeven's RC 1001 Brontes, ID-Cooling's IS-VC45 and the Shadow Rock LP from be quiet!.

One of the nice things about requesting review items is that manufacturers always want to send you a myriad of extras to test along with the product you requested, which is just one of the many benefits of being a Tom's Hardware product reviewer. A handful of compact cases we requested also showed up with an extra CPU cooler (or two) for us to test. In addition to the extra coolers that showed up, we've also received a couple of CPU coolers from other manufactures that requested we test their products. With a fair assortment of compact CPU coolers now on hand, we decided it's time for a round-up.

Since we already have a reference platform put together for testing Mini-ITX computer cases, we'll be using it for today's tests. Additionally, we'll be using the Cougar QBX as our go-to case for compact cooler testing as it's specifically designed to handle small coolers that pull air in from the side of the case and vent it down towards the motherboard. Finally, to improve airflow and reduce heat inside the case, we're swapping out the reference platform's power supply for SilverStone's modular SX600-G 600W power supply.

For today's round-up, we'll be reviewing coolers from SilverStone, Reeven, ID-Cooling, and be quiet!. Additionally, we'll be using the well-reviewed NH-L12 from Noctua as a baseline for today's tests.

Specifications

SilverStone Argon AR06

No Review

$39.99Amazon

Height

2.3" (58mm)

Width

4.1" (105mm)

Depth

3.6" (92mm)

Base Height

✗

Assy. Offset

✗

Cooling Fans

1x 92 x 15mm

Connectors

(1) PWM

Weight

13 Ounces

TDP

95W

Intel Sockets

115x

AMD Sockets

4-bolt Rectangular

Warranty

1 Year
Reeven RC-1001b Brontes

No Review

$39.95Performance PCs

Height

2.3" (59mm)

Width

4.1" (105mm)

Depth

4.5" (114mm)

Base Height

0.7"

Assy. Offset

✗

Cooling Fans

1x 100 x 12mm

Connectors

(1) PWM

Weight

12 Ounces

TDP

95W

Intel Sockets

115x, 1366, 775

AMD Sockets

4-bolt Rectangular

Warranty

2 Years
ID-Cooling IS-VC45

No Review

$80.00Amazon

Height

1.8" (45mm)

Width

3.6" (92mm)

Depth

3.6" (94mm)

Base Height

✗

Assy. Offset

✗

Cooling Fans

1x 92 x 15mm

Connectors

(1) PWM

Weight

12 Ounces

TDP

130W

Intel Sockets

115x, 2011x

AMD Sockets

✗

Warranty

3 Years
be quiet! Shadow Rock LP

No Review

$63.40Amazon

Height

3.0" (75.4mm)

Width

4.8" (122mm)

Depth

5.3" (134mm)

Base Height

0.4"

Assy. Offset

✗

Cooling Fans

1x 120 x 25mm

Connectors

(1) PWM

Weight

14 Ounces

TDP

130W

Intel Sockets

115x115x, 2011x, 1366, 7752011x

AMD Sockets

4-bolt Rectangular

Warranty

3 Years
Noctua NH L12

Review

$69.99Amazon

Height

3.66" (93mm*)

Width

5.0" (128mm)

Depth

5.9" (150mm)

Base Height

0.5"

Assy. Offset

✗

Cooling Fans

1x 120 x 25mm & 1x 92 x 25mm

Connectors

(2) PWM

Weight

24 Ounces

TDP

140W

Intel Sockets

115x, 2011x, 1366, 775

AMD Sockets

4-bolt Rectangular

Warranty

6 Years

SilverStone Argon AR06 Reeven RC-1001b Brontes ID-Cooling IS-VC45
be quiet! Shadow Rock LP Noctua NH L12

MORE: Best CPU Cooling
MORE: Latest Cooling News
MORE: All Cooling Content

Summary
