Surveillance Hard Drive Shoot-Out: WD And Seagate Square Off

Results: WD Surveillance Benchmark, Distributions

For the first test case, WD is the clear winner with 59% of its reads completing in under 5 ms. The Surveillance HDD has its read completion times distributed in the 10-40 ms span.

In the next two test cases, Seagate takes a slight lead, with a higher percentage of completions in the 10 to 20 ms range. The WD Purple also reports a much higher percentage of completions greater than 80 ms. We were hoping that the great results from the first test case would carry over to others, but both drives look similar in these subsequent runs.

  • CaptainTom
    Didn't even know these existed...
    Reply
  • coolestcarl
    Excellent article. I was doing research into building a custom surveillance system for our shop and this is exactly the kind of material that would help me make an informed decision.
    Reply
  • coolestcarl
    One thing that was unclear... obviously WD recommends no more than 8 in a system because of the lack of RAFF. I was wondering:
    Are there any demonstrable effects on performance of having these drives in a small external raid array (of perhaps 4 drives)?
    Reply
  • AndrewJacksonZA
    "As I noted earlier, those Seagate models are in there as a performance reference; they wouldn't normally compete in the same space as the Purple and Surveillance HDD."

    If you're going to wander into the USD1/GB+ territory, even just for informational purposes, please include an SSD in this mix to be fair. SSD performance/price just might validate people buying them for surveillance drives.

    Thank you.
    Reply
  • InvalidError
    I would have whacked a WD Black in there to see how all these specialty drives compare against a standard performance-oriented desktop drive.
    Reply
  • mapesdhs
    I would have whacked a WD Black in there to see how all these specialty drives compare against a standard performance-oriented desktop drive.

    Indeed, or any typical Enterprise SATA model (Hitachi HUS, Seagate ES2/NS, etc.)

    Come to think of it, given the consequences of not being able to identify a suspect or
    obtain other relevant visual information due to dropped data, as AndrewJacksonZA
    says it would be interesting to know how these drives compare to various high-capacity
    SSHDs/SSDs, eg. the Seagate 4TB ST4000DX001, Samsung 840 EVO 1TB (which includes
    AES), and (high-density option, power saving) the Samsung MZ-MTE1T0BW 1TB mSATA.
    The higher cost/GB of these products is surely more than worth it given the intended task.

    Ian.

    Reply
  • CaedenV
    Great article! I had no idea at just how huge the performance gap was between the cheap consumer drives and their more industrial cousins in the enterprise market. Have to say though; with enterprise SSDs starting to come down in price with such better specs, it is going to be difficult to justify enterprise hard drives that still cost $1+/GB. I think we are going to see SSD adoption grow like crazy in those enterprise markets the next few years, especially with drives starting to have 5-10 year warranties.

    Article idea: No offence to the writers at Tom's but this is the first interesting article I have read in a long time. Could we get some more articles like this? Maybe some articles comparing onboard Intel RAID with different popular card options? Or comparing how different drives perform in different RAID configurations and workloads? I get the feeling that these drives would perform quite differently as they are really made to work as a team rather than as solo drives.
    Reply
  • InvalidError
    13537984 said:
    Come to think of it, given the consequences of not being able to identify a suspect or obtain other relevant visual information due to dropped data
    You would need one grossly under-engineered surveillance system for this to really be a problem since there is nothing happening 99% of the time and those drops would need to conveniently happen during the 1% of the time where you need data and your system administrator would need to have somehow failed to notice and fix the issues in-between events if they were so bad as to render the system unusable for its intended purpose.

    Most of the time though, surveillance recordings are merely a nice convenience in case something goes wrong but are not considered critical outside of casinos, banks and few other (very) high security applications that have their own IT departments or dedicated vendors working on their video archival needs and are unlikely to take their hardware recommendations from enthusiast sites like THG.

    I doubt any normal company would waste SSDs or 10k/12k/15k RPM HDDs on video surveillance storage. They would be more likely to use standard HDDs like WD Black / Red / Green / Blue.
    Reply
  • Amdlova
    seagate in enterprise sector is better than WD. i See these little boys working on a PC and DO such amazing job. Running windows and a old Surveillance card with 32 cameras and you can see the videos and edit at same time.
    Reply
  • drewriley
    13537984 said:
    Come to think of it, given the consequences of not being able to identify a suspect or
    obtain other relevant visual information due to dropped data, as AndrewJacksonZA
    says it would be interesting to know how these drives compare to various high-capacity
    SSHDs/SSDs, eg. the Seagate 4TB ST4000DX001, Samsung 840 EVO 1TB (which includes
    AES), and (high-density option, power saving) the Samsung MZ-MTE1T0BW 1TB mSATA.
    The higher cost/GB of these products is surely more than worth it given the intended task.

    Ian.

    I really debated on whether to include SSDs in the evaluation. The problem is that because of $/GB and write endurance, it would only make sense to use them on a smaller scale setup, which is where their benefits (simultaneous high speed IO), are greatly reduced. Also, their performance would skew the graphs to the point where it would be hard to interpret the results of the HDDs.
    Reply
